Pretul Electric Peripheral Water Pump User Manual

1. Introduktion

Thank you for choosing the Pretul BOAP-1/2P3 Electric Peripheral Water Pump. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your pump. Please read this manual thoroughly before use and keep it for future reference.

Vigtige sikkerhedsoplysninger

ADVARSEL: Manglende overholdelse af disse sikkerhedsinstruktioner kan resultere i elektrisk stød, brand, alvorlig personskade eller død.

• Always disconnect the pump from the power supply before performing any maintenance or installation.
• Ensure the pump is installed in a covered, dry, and well-ventilated area.
• Do not operate the pump in environments where the ambient temperature exceeds 40°C (104°F).
• Ensure all electrical connections are properly insulated and protected from water.
• Do not run the pump dry. Always ensure the pump is completely filled with clean water before starting.
• Secure the pump horizontally on a flat surface using screws to prevent movement during operation.
• This pump is designed for pumping clean water only. Do not use it for flammable liquids, corrosive chemicals, or water containing abrasive particles.

2. Produktet er slutview

The Pretul BOAP-1/2P3 is a robust electric peripheral water pump designed to generate high pressure and lift water to significant altitudes. Its compact design and durable components ensure reliable performance.

Nøglefunktioner:

• Generates greater pressure and raises water to a higher altitude compared to centrifugal pumps.
• Single-phase electric motor with aluminum coils for efficient operation.
• Durable brass impeller for constant pressure and long lifespan.
• Integrated heat shield for engine protection against overheating.
• Continuous working capacitor for stable performance.

Components Diagram:

Billedbeskrivelse: An exploded diagram of the Pretul BOAP-1/2P3 pump, highlighting key internal and external components. Labels indicate: Thermal protector, Continuous working capacitor, Motor with aluminum coils, Metal bearing for longer lifespan, Brass impeller for constant pressure, and Enclosed electric motor with external ventilation.

Billedbeskrivelse: Two images showing the front and side views of the yellow Pretul BOAP-1/2P3 electric peripheral water pump. The pump has a black motor housing and a yellow pump body with a brass inlet/outlet.

3. Opsætning og installation

Proper installation is crucial for the pump's performance and longevity. Follow these guidelines carefully:

1. Beliggenhed: Install the pump in a covered, dry, and well-ventilated area. Avoid direct exposure to rain, excessive humidity, or temperatures above 40°C (104°F).
2. Montering: Place the pump horizontally on a flat, stable surface. Secure the pump firmly using screws through the designated mounting holes to prevent vibration and movement during operation.
3. Rørføring: Connect the inlet pipe to your water source (e.g., tank or cistern) and the outlet pipe to your desired discharge point. Ensure all connections are airtight to prevent air leaks, which can affect pump performance. Use appropriate thread sealant.
4. Grunding: Before the first use, or if the pump has run dry, completely fill the pump casing with clean water through the priming port. This ensures the pump is ready to create suction.
5. Elektrisk tilslutning: Connect the pump to a suitable power supply as specified in the technical specifications. Ensure the voltage matches the pump's requirements. Use a grounded outlet and avoid extension cords if possible. If an extension cord is necessary, ensure it is rated for outdoor use and has adequate gauge.

Billedbeskrivelse: A diagram illustrating the pump's operation, showing it drawing water from a tank and raising it to a higher point. Alongside, a performance curve graph (Altura (m) vs. Flujo (L/min)) indicates the recommended use area for the BOAP-1/2P3 model, demonstrating its ability to generate pressure and flow.

Billedbeskrivelse: An infographic displaying key recommendations for the pump: install in covered places, dry and well-ventilated, in environments not exceeding 40°C, fill completely with clean water before first use, and place horizontally on flat surfaces, securing with screws.

4. Betjeningsvejledning

Når pumpen er korrekt installeret og klargjort, kan du begynde at bruge den:

1. Sørg for, at alle forbindelser er sikre, og at der ikke er lækager.
2. Verify that the pump casing is completely filled with water.
3. Connect the pump to the power supply. The pump will start operating.
4. Monitor the pump during its initial operation to ensure proper water flow and pressure.

Driftscyklus:

This pump is designed for intermittent use. To ensure optimal performance and longevity, adhere to the following duty cycle:

• Maximum continuous operation: 20 minutter.
• Minimum rest period after operation: 15 minutter.
• Do not operate the pump for more than 6 timer om dagen i alt.

Adhering to this duty cycle prevents overheating and extends the life of the motor and components.

5. Vedligeholdelse

Regular maintenance ensures the efficient and safe operation of your pump. Always disconnect the pump from the power supply before performing any maintenance.

• Regelmæssig inspektion: Periodically check the pump for any signs of damage, leaks, or unusual noises.
• Renhed: Keep the pump exterior clean and free from dust and debris to ensure proper ventilation.
• Forbindelser: Inspect all pipe connections and electrical wiring for tightness and integrity. Tighten any loose connections.
• Vinterisering (hvis relevant): If the pump is exposed to freezing temperatures, drain all water from the pump and pipes to prevent damage from ice expansion. Store in a dry, frost-free location.

6. Fejlfinding

This section provides solutions to common issues you might encounter with your pump.

Hvis problemet fortsætter efter at have forsøgt disse løsninger, bedes du kontakte kundesupport.

7. Tekniske specifikationer

Billedbeskrivelse: A diagram showing the key dimensions of the Pretul BOAP-1/2P3 pump: Height (Alto) 15 cm, Base 12 cm, and Depth (Fondo) 24 cm.

8. Garanti og support

Garantioplysninger:

Pretul products are manufactured to high-quality standards. For specific warranty terms and conditions, please refer to the warranty card included with your product packaging or visit the official Pretul webwebsted. Behold din købskvittering som købsbevis i tilfælde af garantikrav.

Kundesupport:

If you have any questions, require technical assistance, or need to report an issue with your pump, please contact Pretul customer support. Contact details can typically be found on the product packaging or the official Pretul webwebsted.

When contacting support, please have your product model number (BOAP-1/2P3) and purchase details ready.
