Brugermanual til GHB-babyalarm

Indledning

The GHB Baby Monitor with Camera is designed to provide reliable and secure monitoring of your baby. Featuring a 3.2-inch LCD display, 2100 mAh battery, 2x zoom, temperature sensor, night vision, and two-way intercom, this system ensures you can keep a watchful eye on your child with peace of mind. The 2.4 GHz wireless technology ensures a stable and interference-free connection.

Produktegenskaber

• Reliable 2.4 GHz Wireless Technology: Ensures stable, interference-free real-time video and audio with 100% privacy and security.
• Lang batterilevetid: 2100 mAh battery offers up to 10 hours in continuous screen mode and 16 hours in ECO mode.
• Intelligent ECO Mode: Activates the screen only when baby noises are detected, extending battery life. Note: Motion detection is not available in this mode.
• Integrated Lullabies: Soothing melodies to help your child sleep restfully.
• HD Night Vision: High-quality infrared night vision for clear monitoring in complete darkness without disturbing LEDs.
• Understøttelse af flere kameraer: Connect up to 4 cameras simultaneously (additional cameras sold separately).
• Temperatursensor: Monitors the room temperature to ensure a comfortable environment for your baby.
• To-vejs intercom: Allows you to speak to your baby remotely.

Hvad er inkluderet

The GHB Baby Monitor package typically includes the following components:

• 1 x babykameraenhed
• 1 x Parent Display Unit
• 2 x Power Adapters (one for camera, one for display)
• 1 x brugermanual

This image illustrates the main components included in the GHB Baby Monitor package: the parent unit with its display and the baby camera unit. Both units are shown with their respective power adapters.

Opsætning

1. Tænder

1. Connect the smaller end of one power adapter to the DC input port on the Baby Camera Unit. Plug the other end into a wall outlet. The camera must be constantly connected to the power supply.
2. Connect the smaller end of the second power adapter to the DC input port on the Parent Display Unit. Plug the other end into a wall outlet.
3. Press and hold the Power button on the Parent Display Unit until the screen turns on.

2. Pairing (Initial Setup)

The camera and monitor are pre-paired at the factory. If they do not connect automatically, or if you are adding a new camera, follow these steps:

• Sørg for, at begge enheder er tændt og inden for rækkevidde.
• On the Parent Display Unit, navigate to the Menu.
• Select the "Camera" or "Add Camera" option.
• Follow the on-screen prompts to initiate pairing. Press the pairing button on the back of the Baby Camera Unit (usually a small button, may require a paperclip) within 10 seconds.
• Once successfully paired, the video feed from the camera will appear on the display.

3. Placering

• Place the Baby Camera Unit at least 1 meter (3 feet) away from the baby's crib to avoid direct contact with the power cord.
• Ensure the camera has a clear, unobstructed view of the baby. The camera angle cannot be controlled remotely and must be adjusted manually.
• Place the Parent Display Unit in a location where you can easily monitor your baby, ensuring it is within the effective range of the camera.

This image demonstrates optimal placement of the GHB Baby Camera Unit in a nursery. The camera is positioned to provide a clear view of the crib, ensuring the baby is always visible on the parent unit's display. Ensure the camera is securely placed on a flat surface or mounted.

Betjeningsvejledning

Forældreenhedskontroller

Familiarize yourself with the buttons on the Parent Display Unit:

• Power knap: Tænder/slukker enheden.
• Menu-knap: Accesses settings and features.
• Navigationsknapper (op/ned/venstre/højre): Bruges til at navigere i menuer og justere indstillinger.
• OK/Vælg knap: Bekræfter valg.
• Lydstyrkeknapper: Justerer lydstyrken.
• Taleknap: Activates the two-way intercom.
• Zoom knap: Forstørrer billedet på skærmen.

ECO-tilstand

To conserve battery life, activate ECO mode:

1. Press the Menu button on the Parent Unit.
2. Navigate to "ECO Mode" or "VOX" settings.
3. Select "On" and adjust the sensitivity level if available. In ECO mode, the screen will turn off, and audio transmission will cease until a sound above the set sensitivity level is detected from the baby's room.

Nattesyn

The night vision feature activates automatically in low-light conditions. The camera uses infrared LEDs to provide a clear black-and-white image of your baby in the dark. No manual activation is required.

Vuggeviser

To play lullabies to your baby:

1. Press the Menu button on the Parent Unit.
2. Navigate to the "Lullaby" or "Music" option.
3. Select a lullaby from the list to play it. You may also have options to loop or stop the music.

Tovejs intercom

For at tale med din baby:

• Press and hold the "Talk" button on the Parent Unit.
• Speak clearly into the microphone on the Parent Unit. Your voice will be transmitted to the Baby Camera Unit.
• Release the "Talk" button to hear your baby again.

Temperaturovervågning

The current room temperature is displayed on the Parent Unit's screen. If the temperature goes outside a preset range (if configurable), an alert may sound. Refer to the menu settings to adjust temperature alert thresholds if available.

This image illustrates the various icons and information displayed on the GHB Baby Monitor parent unit screen, including signal strength, battery level, temperature reading, and active features like ECO mode or lullabies.

Opretholdelse

Rensning

• Always disconnect the power adapters before cleaning.
• Wipe the surfaces of the Baby Camera Unit and Parent Display Unit with a soft, damp klæde.
• Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• Ensure no liquid enters the units.

Batteripleje

• The Parent Display Unit contains a rechargeable Lithium Ion battery.
• For optimal battery life, fully charge the unit before first use.
• Undgå ekstreme temperaturer, da disse kan påvirke batteriets ydeevne.
• If storing the unit for an extended period, charge the battery periodically to maintain its health.

Fejlfinding

This image shows the GHB Baby Monitor camera unit positioned in a typical nursery environment, demonstrating proper placement for optimal monitoring and signal reception, which is crucial for troubleshooting connectivity issues.

Specifikationer

This image visually represents the clear night vision capability of the GHB Baby Monitor, showing a baby in a crib in a dark room, demonstrating how the infrared LEDs provide a crisp, black-and-white image without disturbing the baby.

Garanti og support

For warranty information and technical support, please refer to the contact details provided on the product packaging or the official GHB webwebsted. Gem din købskvittering som købsbevis i tilfælde af garantikrav.

For yderligere assistance kan du også kontakte sælgeren via den platform, hvor produktet blev købt.
