Indledning
This manual provides essential information for the safe and efficient use of your Feit Electric BP50JCD/830/LED T4 LED Light Bulb. This 50-watt equivalent bulb features a GY6.35 bi-pin base, offers dimmable functionality, and emits a 3000K warm white light. It operates at 120V and is designed for various lighting applications, including chandeliers and decorative fixtures.
The bulb consumes only 4.5 watts of electricity while producing 500 lumens, offering significant energy savings compared to traditional incandescent bulbs. It is designed for a long lifespan, rated for up to 10,000 hours, and is 100% mercury-free and RoHS compliant.
Figur 1: Feit Electric T4 LED Light Bulb with GY6.35 Bi-Pin Base. This image displays the compact design of the LED bulb, highlighting its bi-pin base for easy installation.
Figur 2: Product packaging for the Feit Electric T4 LED Light Bulb. The packaging indicates key features such as 50-watt equivalent, 4.5W power consumption, 10,000 hours lifespan, 3000K warm white color, and 120V operation.
Opsætning og installation
Before installing the bulb, ensure the power to the fixture is turned off at the circuit breaker to prevent electrical shock. This bulb is designed for fixtures requiring a GY6.35 bi-pin base and 120V AC power supply.
- Bekræft kompatibilitet: Confirm that your fixture requires a GY6.35 bi-pin base and operates on a 120-volt AC electrical system. Using this bulb with an incompatible voltage (e.g., 12V DC) will result in malfunction or damage.
- Fjern gammel pære: Carefully remove the existing bulb from the fixture. Allow it to cool if it was recently in use.
- Indsæt ny pære: Align the two pins of the Feit Electric LED bulb with the corresponding holes in the fixture's socket. Gently push the bulb straight into the socket until it is seated firmly. Do not force the bulb, as this may damage the pins or the socket.
- Gendan strøm: Når pæren er sikkert installeret, skal du genoprette strømmen til armaturet ved afbryderen.
- Test funktionalitet: Tænd lyskontakten for at bekræfte, at pæren fungerer korrekt.
Vigtig bemærkning: This bulb is rated for 120V. Please check your fixture's voltage requirements carefully before installation. Incorrect voltage can lead to bulb failure or safety hazards.
Figur 3: Detailed specifications and dimensions of the T4 JCD LED Bulb with GY6.35 Base. This diagram illustrates the physical size and key electrical characteristics of the bulb, aiding in proper fit and compatibility.
Betjeningsvejledning
The Feit Electric BP50JCD/830/LED bulb is designed for straightforward operation in compatible fixtures. Once installed and power is restored, simply use the fixture's switch to turn the light on or off.
- Dæmpbar funktionalitet: This LED bulb is fully dimmable. When used with a compatible LED dimmer switch, you can adjust the light output to your desired brightness level. Ensure your dimmer switch is rated for LED bulbs to avoid performance issues.
- Varmt hvidt lys: The bulb produces a 3000K warm white light, creating a comfortable and inviting atmosphere suitable for various indoor and outdoor applications.
- Øjeblikkelig tændt: Pæren giver øjeblikkelig fuld lysstyrke uden behov for opvarmningstid.
Figur 4: An outdoor wall sconce demonstrating the flicker-free illumination provided by the Feit Electric LED bulb. This highlights the bulb's stable light output, suitable for various specialty applications.
Figur 5: Examples of common applications for the Feit Electric LED bulb, including bedside lamps, landscape lighting, decorative pendant lights, and wall sconces, illustrating its versatility.
Opretholdelse
The Feit Electric BP50JCD/830/LED light bulb is designed for minimal maintenance due to its long lifespan and durable LED technology. Under normal operating conditions, no regular maintenance is required.
- Rensning: If the bulb requires cleaning, ensure the power is turned off and the bulb is cool. Gently wipe the bulb with a soft, dry cloth. Do not use liquid cleaners or abrasive materials, as these can damage the bulb.
- Levetid: With an average rated life of 10,000 hours (approximately 9 years based on 3 hours/day), this bulb significantly reduces the frequency of replacements.
Figur 6: An image highlighting the long-lasting and energy-efficient attributes of the Feit Electric LED bulb. It emphasizes a 10,000-hour lifespan and an estimated annual energy cost of $0.54.
Fejlfinding
If you encounter issues with your Feit Electric LED light bulb, refer to the following troubleshooting steps:
- Pæren lyser ikke:
- Ensure the power to the fixture is on at both the switch and the circuit breaker.
- Check that the bulb is securely seated in the socket. Remove and reinsert if necessary.
- Verify that the fixture is receiving the correct 120V AC power.
- Test the bulb in another known working fixture, if available, to determine if the issue is with the bulb or the fixture.
- Pæreflimren:
- Ensure the dimmer switch, if used, is compatible with LED bulbs. Older incandescent-only dimmers may cause flickering.
- Kontroller for løse forbindelser i armaturet eller ledningerne.
- Verify that the bulb is receiving stable 120V AC power. Power fluctuations can cause flickering.
- Forkert bindtage Ansøgning:
- This bulb is designed for 120V AC. If installed in a 12V DC system, it will not function correctly and may be damaged. Always confirm your fixture's voltage-krav før installation.
Specifikationer
Detailed technical specifications for the Feit Electric BP50JCD/830/LED T4 LED Light Bulb:
| Specifikation | Værdi |
|---|---|
| Modelnummer | BP50JCD/830/LED |
| Lys type | LED |
| Pære form størrelse | T4 |
| Pære base | GY6.35 Bi-Pin |
| Wattage | 4.5 watt |
| Glødelignende ækvivalent | 50 watt |
| Lysstyrke | 500 lumen |
| Lys farve | 3000K varm hvid |
| Voltage | 120 volt |
| Dæmpbar | Ja |
| Gennemsnitligt liv | 10,000 timer |
| Color Rendering Index (CRI) | 80 |
| Strålevinkel | 300 grader |
| Materiale | Plast |
| Produktdimensioner | 0.6 cm B x 2.5 cm H |
| Certificering | RoHS Compliant, CEC Certified |
Figur 7: An infographic summarizing the key benefits and features of the Feit Electric LED bulb, including its long lifespan, energy efficiency, high CRI, and dimmable capability.
Garantioplysninger
Feit Electric tilbyder en 2 års producentgaranti for this product. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. For specific terms and conditions, refer to the official Feit Electric warranty policy or contact customer support.
Støtte
For further assistance, technical support, or to inquire about warranty services, please visit the Feit Electric support webwebsted:
You can also find additional resources and frequently asked questions on their support portal.
Figur 8: An image promoting 24/7 customer support, featuring a QR code and the web address feit.com/help for easy access to assistance.
