Ufesa SV1200 Automatisk Strygning og Tørring Mannequin Brugermanual

1. Introduktion

Thank you for choosing the Ufesa SV1200 Automatic Ironing and Drying Mannequin. This innovative appliance is designed to simplify your garment care routine by providing a 2-in-1 function for drying and ironing. It effectively eliminates wrinkles, deodorizes, and neutralizes odors, saving you time and energy. This manual provides essential information for the safe and efficient use of your new appliance.

Billede 1.1: The Ufesa SV1200 Automatic Ironing and Drying Mannequin in use, smoothing a shirt in a home environment.

2. Vigtige sikkerhedsinstruktioner

Læs alle sikkerhedsinstruktioner omhyggeligt, inden apparatet tages i brug. Manglende overholdelse af disse instruktioner kan resultere i elektrisk stød, brand eller alvorlig personskade.

• Sørg altid for, at voltagDen angivne strømstyrke på apparatet stemmer overens med din lokale elnetforsyning.tage før tilslutning.
• Nedsænk ikke apparatet, netledningen eller stikket i vand eller anden væske.
• Hold apparatet utilgængeligt for børn og kæledyr.
• Unplug the appliance from the power outlet when not in use, before cleaning, or before performing any maintenance.
• Use the appliance on a stable, flat, and heat-resistant surface.
• Brug ikke apparatet med en beskadiget ledning eller et beskadiget stik, eller hvis apparatet ikke fungerer korrekt eller er blevet beskadiget på nogen måde.
• Do not block the air vents during operation. Ensure adequate ventilation around the unit.
• Undgå at røre ved varme overflader. Brug håndtag eller knopper.
• Dette apparat er kun til husholdningsbrug. Må ikke bruges udendørs.

3. Pakkens indhold

Kontroller, at alle varer er til stede og i god stand ved udpakning:

• Ufesa SV1200 Main Unit
• Inflatable Mannequin Body
• Adjustable Pole with Hanger
• Vægt Clamps (2 enheder)
• Brugervejledning (dette dokument)

4. Dele diagram

Familiarize yourself with the components of your Ufesa SV1200.

Billede 4.1: The Ufesa SV1200 Mannequin showing the main unit, inflatable body, and adjustable pole.

Billede 4.2: Detail of the control knob, indicating timer settings and power switch.

• Hovedenhed (base)
• Justerbar pol
• Inflatable Mannequin Body
• Timer/Power Control Knob
• Strømledning (ikke vist)
• Vægt Clamps (ikke vist)

5. Opsætning og montering

Follow these steps to assemble your Ufesa SV1200:

1. Placer hovedenheden på en stabil, plan overflade.
2. Insert the adjustable pole into the designated slot on the main unit. Ensure it is securely seated.
3. Attach the inflatable mannequin body to the top of the adjustable pole. The mannequin body should fit snugly over the air outlet.
4. Ensure the mannequin body's zipper is closed to maintain inflation.

Billede 5.1: Illustration of the assembly process, connecting the adjustable pole to the main unit.

6. Betjeningsvejledning

6.1. Garment Preparation

1. For best results, use garments that are damp, such as those just removed from a washing machine (after spinning).
2. Carefully place the garment (e.g., shirt, blouse) onto the inflatable mannequin body.
3. Adjust the mannequin's zipper closure to ensure a snug fit for your garment. The mannequin accommodates sizes from S to XXL.
4. Attach the provided weight clamps to the bottom hem of the garment. This helps to stretch the fabric and minimize wrinkles during the drying and ironing process.

Billede 6.1: A shirt correctly placed on the mannequin, ready for operation.

6.2. Betjening

1. Sæt netledningen i en passende stikkontakt.
2. Turn the control knob to select the desired operating time. Options typically range from 30 minutes up to 180 minutes (3 hours). The appliance will begin to inflate the mannequin and generate warm air.
3. The warm air circulates through the garment, drying it and smoothing out wrinkles. This process also helps to deodorize and neutralize odors.

Billede 6.2: Diagram illustrating the warm air circulation path within the garment for effective drying and wrinkle removal.

6.3. Færdiggørelse

1. Once the selected time has elapsed, the appliance will automatically shut off.
2. Carefully remove the garment from the mannequin. It should be dry and significantly smoother.
3. Tag apparatet ud af stikkontakten.

7. Vedligeholdelse og pleje

Proper maintenance ensures the longevity and optimal performance of your Ufesa SV1200.

• Tag altid stikket ud af stikkontakten før rengøring.
• Tør hovedenhedens yderside af med en blød, tør klud.amp klæde. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• The inflatable mannequin body can be wiped clean with a damp cloth if necessary. Ensure it is completely dry before storage.
• Opbevar apparatet på et køligt, tørt sted, når det ikke er i brug.
• Do not wrap the power cord tightly around the appliance; store it loosely to prevent damage.

8. Fejlfinding

If you encounter any issues with your Ufesa SV1200, refer to the following table for common problems and solutions.

9. Tekniske specifikationer

• Model: SV1200
• Magt: 1200 W
• Voltage: 230 V
• Timer: Op til 3 timer (180 minutter)
• Dimensioner (samlet): Approximately 40.5 x 23 x 31 cm (Height x Width x Depth)
• Vægt: Cirka 3.95 kg
• Materiale: Plast, aluminium
• Supported Garment Sizes: S, M, L, XL, XXL

Billede 9.1: Dimensionel overview of the Ufesa SV1200 Automatic Ironing and Drying Mannequin.

10. Garanti og support

Your Ufesa SV1200 Automatic Ironing and Drying Mannequin is covered by a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions.

For technical support, service, or inquiries regarding your product, please contact your retailer or the Ufesa customer service department. Contact information can typically be found on the Ufesa official webwebstedet eller på din købsdokumentation.
