hansgrohe Ecostat Comfort Single Function Surface Mounted Shower Thermostat - Matt Black User Manual

Indledning

This manual provides detailed instructions for the installation, operation, and maintenance of your hansgrohe Ecostat Comfort Single Function Surface Mounted Shower Thermostat in Matte Black. Designed for comfort and reliability, this thermostat ensures precise temperature control and water flow for your shower.

Please read these instructions thoroughly before installation and use to ensure proper function and longevity of your product. Keep this manual for future reference.

Produkt overview

Billede 1: Front view of the hansgrohe Ecostat Comfort Single Function Surface Mounted Shower Thermostat in Matte Black. It features two ergonomic rotating handles and a central spout connection.

The hansgrohe Ecostat Comfort thermostat combines a modern SoftCube design with a durable matte black finish. It is engineered for surface-mounted installation, making it suitable for existing S-connections (DN 15). Key features include:

• Præcis temperaturkontrol: Maintains desired water temperature, protecting against sudden changes.
• SafetyStop: A button on the handle prevents accidental adjustment to temperatures above 40 °C.
• EcoStop: Limits water flow to 10 L/min initially, with an option to release full flow.
• Ergonomiske håndtag: Designed for easy adjustment of water volume and temperature.
• Stille drift: Built-in silencer reduces water flow noise.

Opsætning og installation

This section outlines the general steps for installing your surface-mounted shower thermostat. It is recommended that installation be performed by a qualified professional to ensure proper function and compliance with local plumbing codes.

Required Tools and Components:

• Justerbar skruenøgle
• Thread seal tape (PTFE tape)
• Niveau
• Bor (hvis der er behov for nye monteringshuller)
• Included S-Connectors, rosettes, and shower thermostat

Installationstrin:

1. Forbered installationsområdet: Ensure the water supply to the shower area is turned off. Remove any existing fixtures.
2. Install S-Connectors: Apply thread seal tape to the threads of the S-connectors. Screw the S-connectors into the wall water outlets. Adjust them to ensure they are level and the correct distance apart (typically 150mm center-to-center for standard installations). The product is designed to fit existing S-connections (DN 15).
3. Fastgør rosetter: Place the decorative rosettes over the S-connectors, flush against the wall.
4. Mount the Thermostat: Carefully align the thermostat with the S-connectors. Hand-tighten the nuts onto the S-connectors. Use an adjustable wrench to securely tighten the connections, being careful not to overtighten.
5. Tilslut bruserslange: Attach your shower hose to the bottom outlet of the thermostat.
6. Tjek for lækager: Slowly turn on the main water supply. Inspect all connections for any signs of leakage. If leaks are present, turn off the water, tighten the connections, and re-check.

Billede 2: Technical drawing illustrating the dimensions and connection points for the hansgrohe Ecostat Comfort Shower Thermostat. This diagram is crucial for ensuring correct S-connector spacing and overall fit.

Betjeningsvejledning

Your hansgrohe Ecostat Comfort thermostat is designed for intuitive operation. It features two rotating handles for controlling water temperature and volume.

Temperaturkontrol:

• Det højre håndtag styrer vandtemperaturen. Drej det for at justere temperaturen.
• SafetyStop: To prevent accidental scalding, the thermostat is equipped with a SafetyStop feature. Water temperatures above 40 °C can only be selected by pressing the button on the handle while rotating it past the 40 °C mark.
• The thermostat will maintain the set temperature, even with minor pressure fluctuations in your water supply.

Water Volume Control:

• The left handle controls the water volume. Rotate it to increase or decrease the flow.
• EcoStop: For water conservation, the water flow is initially limited to approximately 10 L/min. To achieve the full flow rate (up to 17 L/min at 3 bar), press the button on the handle while rotating it further.

Billede 3: En eksample of the hansgrohe shower system installed in a modern bathroom setting, showcasing its aesthetic integration and functional design.

Vedligeholdelse og pleje

Proper care will ensure the longevity and appearance of your hansgrohe Ecostat Comfort thermostat, especially its matte black finish.

Rengøringsvejledning:

• Use only soft cloths and mild cleaning agents. Avoid abrasive cleaners, scouring pads, or solvents, as these can damage the matte black finish.
• Do not use cleaning agents containing hydrochloric acid, formic acid, chlorine bleach, or acetic acid, as these can cause significant damage.
• Rinse the thermostat thoroughly with clean water after cleaning to remove any residue.
• Dry the surface with a soft cloth to prevent water spots.
• Regular, gentle cleaning is recommended to maintain the finish and prevent mineral buildup.

Generel vedligeholdelse:

• Kontroller jævnligt alle forbindelser for utætheder.
• If water flow decreases, check the shower head for limescale buildup and clean as necessary.

Fejlfinding

If you encounter issues with your thermostat, refer to the following common problems and solutions before contacting customer support.

Specifikationer

Garanti og support

Garantioplysninger:

hansgrohe offers a 5-year voluntary warranty on this product, manufactured to high-quality standards. This warranty covers defects in materials and workmanship under normal use and service. Please retain your proof of purchase for warranty claims.

Kundesupport:

For technical assistance, spare parts, or warranty claims, please contact hansgrohe customer service. Refer to the official hansgrohe webwebstedet eller din købsdokumentation for aktuelle kontaktoplysninger.

You can also visit the official hansgrohe store for more information: hansgrohe Store
