LAUNCH CRP129X V2.0 Autodiagnostisk Scanner Brugermanual

1. Introduktion

The LAUNCH CRP129X V2.0 is a professional automotive diagnostic tool designed to help users identify and resolve common vehicle issues. It offers comprehensive system diagnostics and a wide range of reset services, making it suitable for both professional mechanics and DIY enthusiasts. This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your device.

2. Produktet er slutview

Figure 2.1: The LAUNCH CRP129X V2.0 diagnostic scanner, showing its main screen with various reset options and a carrying case in the background. The screen displays options like A/F Reset, Brake Reset, Oil Reset, SAS Reset, Battery Reset, Bleeding, Elec Throttle RLRN, TPMS Reset, DPF Reg, AdBlue Reset, AFS Reset, and Injector.

Figure 2.2: A visual comparison illustrating the evolution of the CRP129X series, highlighting upgrades in reset functions (from 2 to 12), RAM (from 2+8GB to 2+32GB), Android version (from 7.0 to 8.1), battery capacity (from 5000mAh to 6100mAh), and supported car brands (from 40 to 80).

Nøglefunktioner:

• 12 Nulstillingstjenester: Includes Oil Reset, BMS Reset, Brake Reset, DPF Regeneration, ETS Reset, Injector Coding, SAS Calibration, TPMS Reset, AdBlue Reset, AFS Reset, Air/Fuel Setting, and ABS Bleeding.
• 4 System Diagnostics: Engine, Anti-lock Braking System (ABS), Supplemental Restraint System (SRS), and Transmission.
• Android 8.1-operativsystem: For smoother and faster operation.
• Expanded Memory: 2GB RAM + 32GB storage for faster startup and more data storage.
• Bred dækning af køretøjer: Supports over 80 car brands, covering most vehicles from 1996 to 2024.
• Livstids gratis softwareopdateringer: Ensures the device stays up-to-date with the latest vehicle models and functions.
• One-Touch AutoVIN: Automatically identifies vehicle information for quick and accurate scanning.
• 4-in-1 Live Data Graph: Displays multiple data streams simultaneously for comprehensive analysis.
• Diagnostic Report Sharing: Generate and share PDF reports via email.
• Online Repair Materials: Access to DTC help, repair cases, and technical handbooks.

3. Opsætning og første brug

3.1 Unboxing and Powering On

Upon receiving your LAUNCH CRP129X V2.0, carefully unbox the device and inspect for any damage. The device does not include a charger; please use a standard USB charger (DC 5V 1A/2A) to power the unit. Connect the device to a power source using the provided USB cable.

3.2 Softwareopdateringer

It is highly recommended to perform a software update immediately after initial setup to ensure you have the latest features and vehicle compatibility. The device supports lifetime free updates via Wi-Fi.

1. Connect the CRP129X V2.0 to a stable Wi-Fi network.
2. Navigate to the "Update" section on the device's main menu.
3. Follow the on-screen prompts to download and install available updates. This process may take some time depending on your internet speed.

Figure 3.1: Illustration indicating that lifetime updates are included with the device, ensuring continuous access to the latest software and features.

4. Betjeningsvejledning

4.1 Tilslutning til et køretøj

Locate your vehicle's OBD-II port, typically found under the dashboard on the driver's side. Connect the diagnostic cable from the CRP129X V2.0 to the vehicle's OBD-II port. Turn the vehicle's ignition to the "ON" position (engine off).

4.2 AutoVIN Scan

The AutoVIN feature allows the device to automatically identify your vehicle's information (VIN, make, model, year) for quick and accurate diagnostics.

1. From the main menu, select "Diagnose" or "AutoVIN".
2. The device will automatically scan and display the vehicle's VIN and other relevant details. Confirm the information is correct.

Figure 4.1: Depiction of the Smart One-Touch AutoVIN function, showing a vehicle and the diagnostic tool automatically retrieving the VIN for fast and accurate scanning.

4.3 System Diagnostics (OBD-II Functions)

The CRP129X V2.0 supports full OBD-II functions, allowing you to read and clear diagnostic trouble codes (DTCs), view live data, freeze frame data, and perform various tests for the Engine, ABS, SRS, and Transmission systems.

Figure 4.2: An illustration showing the four main systems the diagnostic tool can scan: Engine, ABS (Anti-lock Braking System), Transmission, and SRS (Supplemental Restraint System), emphasizing one-touch scan, code search, and a built-in DTC library.

4.3.1 Engine System Diagnostics

This function allows you to read and clear engine-related DTCs, turn off the Check Engine Light (MIL), and view live data streams to diagnose issues such as misfires, sensor malfunctions, and fuel system problems.

4.3.2 Anti-lock Braking System (ABS) Diagnostics

Diagnose ABS system issues by reading and clearing ABS-related DTCs. Common problems include faulty wheel speed sensors or ABS module malfunctions. After repairs, you can reset the ABS warning light.

4.3.3 Supplemental Restraint System (SRS) Diagnostics

Access the SRS system to read and clear airbag-related fault codes. This helps ensure the airbag system is functioning correctly, which is crucial for occupant safety.

4.3.4 Transmission System Diagnostics

Monitor the transmission system by reading and clearing transmission-related DTCs and viewing live data. This helps identify issues affecting gear shifts, clutch operation, and overall transmission performance.

4.4 12 Reset Services

The CRP129X V2.0 offers 12 commonly used reset and maintenance services:

Figure 4.3: A visual representation of the 12 most frequently used reset functions available on the CRP129X V2.0, including AdBlue Reset, AFS Reset, Air/Fuel Setting, ABS Bleeding, Oil Reset, BMS Matching, Brake Reset, TPMS Reset, DPF Regeneration, Throttle Adaptation, Injector Coding, and SAS Calibration.

1. Olie nulstilling: Resets the oil life system and turns off the oil change light after an oil service.
2. BMS Matching (Battery Management System): Registers a new battery replacement to the vehicle's ECU to ensure proper charging and system function.
3. Brake Reset (EPB Reset): Nulstiller det elektroniske parkeringsbremsesystem efter udskiftning af bremseklodser.
4. DPF-regenerering (dieselpartikelfilter): Manages DPF regeneration to clear trapped particulate matter and maintain filter efficiency.
5. ETS Reset (Electronic Throttle System / Throttle Adaptation): Relearns the throttle body's operating parameters after cleaning or replacement to ensure smooth acceleration and idle.
6. Injektorkodning: Codes new injector numbers into the ECU after replacement to ensure correct fuel delivery.
7. SAS Calibration (Steering Angle Sensor): Calibrates the steering angle sensor after steering-related repairs to ensure proper vehicle stability control.
8. TPMS Reset (Tire Pressure Monitoring System): Resets tire pressure sensors after tire rotation, replacement, or sensor replacement.
9. AdBlue-nulstilling: Resets the Diesel Exhaust Fluid (AdBlue/DEF) system after refilling or component replacement.
10. AFS Reset (Adaptive Front-lighting System): Resets or recalibrates the adaptive front-lighting system after maintenance or repair.
11. Air/Fuel Setting: Adjusts or learns the air/fuel ratio parameters.
12. ABS-blødning: Performs brake bleeding procedures to remove air from the ABS system, ensuring a firm brake pedal.

4.5 Grafisk fremstilling af livedata

The device can display live data streams in a graphical format, allowing you to monitor multiple parameters simultaneously (up to 4 PIDs on one screen). This is crucial for diagnosing intermittent issues and observing system behavior in real-time.

Figure 4.4: The diagnostic tool displaying multiple PIDs (Parameter IDs) in a live data graph, showing real-time status for various vehicle parameters like coolant temperature, vehicle speed, and battery voltage.

4.6 Diagnostic Report and Online Resources

After completing a diagnostic session, you can generate a detailed PDF report. This report can be saved, printed, or shared via email for further analysis or record-keeping.

The CRP129X V2.0 also provides access to an online repair database, including:

• DTC Help: Provides repair information related to specific error codes.
• Technology Handbook: Offers extensive technical information for various car models.
• Repair Cases: Real-world repair processes for specific vehicle issues.
• Onlinefeedback: Allows users to submit operational difficulties or troubleshooting problems to LAUNCH professionals for personalized assistance.

Figure 4.5: An icon representing the Cloud Report feature, indicating the ability to generate and manage diagnostic reports in the cloud.

5. Vedligeholdelse

To ensure the longevity and optimal performance of your LAUNCH CRP129X V2.0, follow these maintenance guidelines:

• Softwareopdateringer: Regularly check for and install software updates to benefit from new features, bug fixes, and expanded vehicle coverage. Updates are free for life.
• Rensning: Rengør enheden med en blød, tør klud. Undgå at bruge slibende rengøringsmidler eller opløsningsmidler.
• Opbevaring: Store the device in its protective carrying case in a cool, dry place when not in use.
• Batteripleje: The device is powered by a Lithium-polymer battery. While it offers over 10 hours of work time, ensure it is charged using a DC 5V 1A/2A USB charger. Avoid extreme temperatures during charging and operation.

6. Fejlfinding

If you encounter issues with your LAUNCH CRP129X V2.0, consider the following common troubleshooting steps:

For further assistance, utilize the "Online Feedback" feature on your device to contact LAUNCH's professional support team.

7. Specifikationer

8. Garanti og support

The LAUNCH CRP129X V2.0 comes with a 5 års garanti for any quality issues. For technical support, operational difficulties, or troubleshooting assistance, please use the "Online Feedback" function available on your device. LAUNCH's certified professionals are available 24/7 to provide personalized repair suggestions.

You can also visit the official LAUNCH brand store for more information: LAUNCH Official Store
