UHPPOTE 2.4GHz WiFi Outswinging Indoor 1200lb Electric Magnetic Door Lock Kit System

1. Introduktion

This manual provides comprehensive instructions for the installation, operation, and maintenance of your UHPPOTE 2.4GHz WiFi Outswinging Indoor 1200lb Electric Magnetic Door Lock Kit System. This system offers secure access control with the convenience of remote and smartphone app control, designed for outswinging indoor doors.

Nøglefunktioner omfatter:

• Wireless RF remote control for convenient door unlocking.
• Smartphone app control via Tuya Smart App (requires 2.4GHz Wi-Fi).
• 1200lb holding force electromagnetic lock for robust security.
• Included exit button for easy indoor egress.
• Timing functions for scheduled lock/unlock operations.
• Share control functionality with other users.

2. Sikkerhedsoplysninger

Please read all safety warnings and instructions carefully before installing and operating this product. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Sørg for, at strømmen er afbrudt før installation eller vedligeholdelse.
• Dette system er designet til indendørs og outswinging doors only.
• Installationen bør udføres af kvalificeret personale, hvis du er i tvivl.
• Brug kun den medfølgende strømadapter.
• Keep all components away from water and excessive humidity.
• Do not attempt to modify or repair the system components yourself. Contact support if issues arise.

3. Pakkens indhold

Bekræft, at alle nedenstående varer er til stede i din pakke:

• 1x Electromagnetic Lock (1200lb holding force)
• 1x Armature Plate
• 1x Remote Control Receiver/WiFi Module
• 2x Wireless RF Remote Transmitters
• 1x Exit Button
• 1x strømadapter (DC 12V)
• Monteringshardware (skruer, ankre osv.)

This image displays all the components included in the UHPPOTE 2.4GHz WiFi Outswinging Indoor 1200lb Electric Magnetic Door Lock Kit. Visible items are the main electromagnetic lock unit, its corresponding armature plate, a power adapter, two wireless remote controls, the central WiFi receiver module, and a push-to-exit button.

4. Installation og opsætning

4.1 Ledningsdiagram

Refer to the following diagram for proper wiring connections. Ensure all connections are secure before applying power.

This diagram illustrates the electrical connections for the UHPPOTE magnetic lock system. It shows how the access keypad (optional, not included in this kit), the WiFi receiver module, the exit button, the power adapter, and the fail-safe electromagnetic lock are interconnected. Pay close attention to the NO (Normally Open), NC (Normally Closed), COM (Common), V+ (Positive), and V- (Negative) terminals.

4.2 Electromagnetic Lock Installation

The electromagnetic lock is designed for outswinging doors. It should be mounted on the door frame, and the armature plate on the door itself.

1. Identify the optimal mounting position on the door frame, ensuring proper alignment with the armature plate on the door.
2. Drill pilot holes and secure the electromagnetic lock to the door frame using the provided screws.
3. Mount the armature plate to the door, ensuring it aligns perfectly with the electromagnetic lock when the door is closed. Use a rubber washer if provided, to allow slight pivot for better contact.

This image shows the main electromagnetic lock unit and its corresponding armature plate. The lock is a rectangular metal bar with visible magnetic coils, and the armature plate is a flat metal piece designed to attach to the door, creating the magnetic bond when the lock is energized.

4.3 WiFi Receiver Module and Remote Pairing

The WiFi receiver module acts as the central control unit. It communicates with the electromagnetic lock, remote controls, and your smartphone via Wi-Fi.

1. Connect the WiFi receiver module according to the wiring diagram (Figure 4.1).
2. Pairing Remote Controls:
   • Press the learning button on the receiver module (refer to the module's specific instructions for exact location, usually a small button).
   • While the indicator light on the receiver is active, press any button on the remote control you wish to pair.
   • The indicator light will flash or change color to confirm successful pairing. Repeat for all remote controls.

This image shows the compact black WiFi receiver module. It features indicator lights, connection ports for the lock and exit button, and clearly labeled WiFi and RF (remote frequency) icons, indicating its dual control capabilities.

This image depicts a hand pressing the button on one of the wireless remote controls included in the kit. The remote is small, black, and silver, designed for convenient, portable operation of the lock system.

4.4 Smartphone App Setup (Tuya Smart App)

The Tuya Smart App allows for remote control and advanced features.

1. Download the "Tuya Smart" app from the App Store (iOS) or Google Play (Android).
2. Registrer dig eller log ind på din Tuya Smart-konto.
3. Tilføj en ny enhed:
   • Sørg for, at din telefon er tilsluttet et 2.4 GHz Wi-Fi-netværk.
   • In the app, tap "+" to add a device.
   • Follow the in-app instructions to put the WiFi receiver module into pairing mode (usually by pressing and holding a button on the module until an indicator light flashes rapidly).
   • Vælg dit Wi-Fi-netværk, og indtast adgangskoden.
   • The app will discover and connect to the device. Once connected, you can rename it.

This image shows a smartphone displaying the Tuya Smart app, which is used to control the magnetic door lock. The screen prominently features a large lock icon and an "OFF" button, indicating the current locked status and the option to unlock the door remotely.

5. Betjeningsvejledning

5.1 Oplåsning af døren

• Using Wireless RF Remote: Press the designated unlock button on the remote control. The lock will temporarily unlock, allowing the door to be opened.
• Using Smartphone App: Open the Tuya Smart App, select your lock device, and tap the "Unlock" or "OFF" button. The lock will temporarily unlock.
• Brug af Exit-knappen: From the inside, press the exit button. The lock will temporarily unlock for egress.

This image shows the rectangular silver exit button with a prominent black push button in the center. It is clearly labeled "PUSH TO EXIT" at the top and "EXIT" at the bottom, indicating its function for quick and easy egress from the secured area.

5.2 Avancerede appfunktioner

• Timing funktion: Set schedules for automatic lock/unlock operations (e.g., unlock during business hours, lock at night). This includes countdown, scheduled on/off, and loop timing.
• Del kontrol: Grant access to family members or trusted individuals by sharing control of the device through the app.
• Grupperingsfunktion: Organize multiple smart devices into groups for easier management within the app.
• Smart scene: Create automated scenarios where the lock interacts with other smart devices (e.g., unlock door when motion is detected).

6. Vedligeholdelse

Regular maintenance ensures optimal performance and longevity of your magnetic door lock system.

• Rensning: Wipe down the electromagnetic lock and armature plate with a soft, dry cloth periodically to remove dust and debris. Do not use abrasive cleaners or solvents.
• Tilslutningskontrol: Kontrollér regelmæssigt alle ledningsforbindelser for at sikre, at de er fastgjorte og fri for korrosion.
• Firmwareopdateringer: Check the Tuya Smart App regularly for any available firmware updates for the WiFi receiver module. Install updates as recommended for improved performance and security.
• Battery Replacement (Remotes): If remote control range decreases or functionality becomes intermittent, replace the CR2 batteries (2 required) in the remote transmitters.

7. Fejlfinding

8. Specifikationer

9. Garanti og support

For warranty information and technical support, please contact UHPPOTE customer service. Refer to the product packaging or the official UHPPOTE webhjemmeside for de seneste kontaktoplysninger.

Online ressourcer kan omfatte:

• UHPPOTE Officiel Webwebsted: Visit the UHPPOTE Store on Amazon
• Product Support Page (if available)
• FAQ sektion

Please have your model number (UT-WIFI-500KG-814A) and purchase date ready when contacting support.
