1. Introduktion
This manual provides comprehensive instructions for the Bud Light Beer Bluetooth Bottle Speaker, Model BL-BBS-002. Designed for portable audio playback, this wireless speaker connects to Bluetooth-enabled devices, offering a unique design and clear sound for various indoor and outdoor activities.
Læs venligst denne manual grundigt, inden produktet tages i brug, for at sikre korrekt funktion og maksimere dets levetid.
Billede 1.1: Forside view of the Bud Light Beer Bluetooth Bottle Speaker.
2. Pakkens indhold
Bekræft, at alle nedenstående varer er til stede i din produktemballage:
- Bud Light Bluetooth Speaker Bottle
- Opladningskabel (Micro USB)
- Brugervejledning (dette dokument)
3. Produktet er slutview
Familiarize yourself with the various components and controls of your Bud Light Bluetooth Bottle Speaker.
Billede 3.1: Side view of the speaker highlighting the control buttons and ports.
- On/Off knap: Tænder eller slukker for højttaleren.
- Aux 3.5mm Port: For wired audio connection using a 3.5mm audio cable (not included).
- Micro USB-opladningsport: Forbinder højttaleren til en strømkilde til opladning.
4. Opsætning
4.1. Opladning af højttaleren
Before initial use, fully charge the speaker. Use the provided Micro USB charging cable.
- Connect the Micro USB end of the charging cable to the Micro USB Charging Port on the speaker.
- Connect the USB-A end of the charging cable to a USB power adapter (e.g., smartphone charger, computer USB port) or a power bank.
- The charging indicator light (if present, refer to product for exact location) will illuminate during charging and turn off or change color when fully charged.
- En fuld opladning tager typisk cirka 2-3 timer.
Note: Do not use damaged charging cables or adapters. Ensure the charging port is dry before connecting the cable.
4.2. Tænd/sluk
- For at tænde: Press and hold the On/Off Button for approximately 3 seconds. You will hear an audible tone, and an indicator light will flash, indicating it is ready for pairing.
- For at slukke: Press and hold the On/Off Button for approximately 3 seconds. You will hear an audible tone, and the indicator light will turn off.
5. Betjeningsvejledning
5.1. Bluetooth-parring
To connect the speaker to your Bluetooth-enabled device (smartphone, tablet, laptop):
- Ensure the speaker is powered on and in pairing mode (indicator light flashing).
- Naviger til Bluetooth-indstillingerne på din enhed.
- Aktiver Bluetooth og søg efter tilgængelige enheder.
- Select "Bud Light Speaker" (or similar name) from the list of found devices.
- Once paired, you will hear a confirmation tone, and the indicator light on the speaker will stop flashing and remain solid.
- Højttaleren vil automatisk forsøge at genoprette forbindelsen til den sidst parrede enhed, når den tændes.
Note: The effective Bluetooth range is approximately 30 feet (9 meters). Obstacles may reduce this range.
5.2. Afspilning af lyd
- After successful Bluetooth pairing, play audio from your connected device.
- Adjust the volume directly from your connected device. The speaker does not have independent volume controls.
- For wired connection, insert a 3.5mm audio cable into the Aux 3.5mm Port on the speaker and the other end into your audio source. Bluetooth will be disabled when the Aux cable is connected.
Image 5.1: The portable speaker in an outdoor setting, demonstrating its use for entertainment.
6. Vedligeholdelse
- Rensning: Wipe the speaker with a soft, dry cloth. Do not use abrasive cleaners, alcohol, or solvents.
- Opbevaring: Opbevar højttaleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
- Vandeksponering: Denne højttaler er IKKE vandtæt. Undgå at udsætte den for vand, regn eller overdreven fugt.
- Batteripleje: To preserve battery life, charge the speaker at least once every three months if not in regular use.
7. Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Højttaleren tænder ikke. | Batteriet er afladet. | Oplad højttaleren ved hjælp af det medfølgende USB-kabel. |
| Kan ikke parre med Bluetooth-enhed. | Bluetooth is off on your device; speaker is not in pairing mode; speaker is already paired to another device; device is out of range. | Ensure Bluetooth is enabled on your device. Power cycle the speaker to enter pairing mode. Disconnect from other devices. Move device closer to speaker (within 30 ft). |
| Ingen lyd under afspilning. | Volume on device is too low; speaker is not connected; audio source issue. | Increase volume on your connected device. Re-pair the Bluetooth connection. Check if the audio source is playing correctly. |
| Lydkvaliteten er dårlig eller forvrænget. | Device is out of Bluetooth range; interference; low battery. | Move device closer to the speaker. Avoid sources of strong electromagnetic interference. Charge the speaker. |
8. Specifikationer
| Modelnavn | BL-BBS-002 |
| Mærke | Bud Lys |
| Forbindelsesteknologi | Bluetooth 5.0 |
| Wireless Range | Op til 30 fod (9 meter) |
| Strømkilde | Batteridrevet (1 litiumpolymerbatteri, inkluderet) |
| Højttaler udgangseffekt | 3 watt |
| Lydudgangstilstand | Stereoanlæg |
| Produktmål (L x B x H) | 6.35 cm D x 6.35 cm B x 22.86 cm H (2.5" D x 2.5" B x 9" H) |
| Varens vægt | 1 kg (0.45 kg) |
| Vandtæt | Ingen |
| Kompatible enheder | Smartphones, Tablets, Laptops, Personal Computers |
9. Garanti og support
This Bud Light Bluetooth Speaker comes with a 1 års begrænset garanti fra købsdatoen. Gem venligst din købsbevis i tilfælde af garantikrav.
The manufacturer is M&S Accessory Network. For support or warranty inquiries, please contact the retailer or manufacturer directly with your proof of purchase and product model number (BL-BBS-002).
Note: Warranty does not cover damage caused by misuse, accidents, unauthorized modifications, or exposure to water.
