1. Introduktion
This manual provides comprehensive instructions for the installation, operation, and maintenance of your Cal-Royal CR-SL50-26D Heavy Duty Cylindrical Lever Set. Please read these instructions carefully before beginning installation or use to ensure proper function and longevity of the product. Retain this manual for future reference.
2. Produktet er slutview
The Cal-Royal CR-SL50-26D is a heavy-duty cylindrical lever set designed for commercial and institutional applications. It features a durable alloy steel construction with a satin chrome finish. This specific model is an exit function lever set, meaning it allows egress from the inside at all times, but does not provide key entry from the outside. It includes a standard 2-3/4 inch deadlatch mechanism.
Figur 2.1: eksploderede view of the Cal-Royal CR-SL50-26D lever set components, showing the internal mechanism and deadlatch.
3. Hvad er der i æsken
Når du åbner pakken, skal du kontrollere, at alle komponenter er til stede:
- Lever Handle Assembly (Interior and Exterior)
- Deadlatch Mechanism
- Monteringshardware (skruer)
- Slagplade
- Installation Template (if provided)
Figur 3.1: Ydre view of the lever set, showing the handle and rose plate.
4. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Cal-Royal |
| Modelnummer | CR-SL50-26D |
| Materiale | Legeret stål |
| Slutte | Satin krom |
| Låsetype | Deadlatch |
| Fungere | Exit Function (No key entry from outside) |
| backset | Standard 2-3/4 inches |
| Varens vægt | 3.6 pund |
| Speciel funktion | Nem at installere |
5. Opsætning og installation
Installation typically requires basic hand tools. Refer to the included installation template for precise drilling instructions if installing on a new door. For replacement installations, ensure existing bore holes match the product specifications.
Nødvendige værktøjer (ikke inkluderet):
- Phillips hovedskruetrækker
- Målebånd
- Blyant
- Drill (for new installations)
Installationstrin:
- Forbered døren: If installing on a new door, use the provided template to mark and drill the necessary holes for the latch and lever set. For existing doors, ensure the bore holes are clean and correctly sized.
- Install the Deadlatch: Insert the deadlatch mechanism into the edge bore hole of the door. Ensure the bevel of the latch bolt faces the door frame. Secure it with the provided screws.
- Install Exterior Lever: Place the exterior lever assembly through the cross bore hole, ensuring the spindle engages with the deadlatch mechanism.
- Install Interior Lever: Align the interior lever assembly with the exterior assembly and the deadlatch. Secure both lever assemblies together using the through-bolts or screws provided. Ensure the levers operate smoothly and the latch retracts fully.
- Installer låseplade: Mark the position of the latch bolt on the door frame. Chisel out a recess for the strike plate and secure it with screws. Ensure the latch bolt engages properly with the strike plate when the door is closed.
Figur 5.1: Indre view of the lever set, showing the handle and rose plate from the inside.
6. Betjeningsvejledning
The Cal-Royal CR-SL50-26D is an exit function lever set. Its operation is straightforward:
- Fra interiøret: Simply depress the lever handle to retract the latch bolt and open the door. The door can always be opened from the inside for emergency egress.
- Udefra: The exterior lever is fixed and does not retract the latch. This model does not allow key entry from the outside. The door can only be opened from the exterior if it is unlocked from the inside or if it is not latched.
7. Vedligeholdelse
Regular maintenance ensures the smooth operation and extends the lifespan of your lever set:
- Rensning: Rengør de udvendige overflader med en blød,amp cloth. Avoid abrasive cleaners or harsh chemicals, as these can damage the satin chrome finish.
- Smøring: Periodically apply a small amount of silicone-based lubricant to the latch bolt and internal mechanisms if you notice stiffness or friction. Do not use oil-based lubricants as they can attract dust and grime.
- Tilspændingsskruer: Over time, mounting screws may loosen. Periodically check and tighten all visible screws to ensure the lever set remains securely attached to the door.
8. Fejlfinding
If you encounter issues with your Cal-Royal CR-SL50-26D lever set, refer to the following common problems and solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Håndtaget er stift eller svært at dreje. | Lack of lubrication, internal debris, or misaligned components. | Apply silicone lubricant to the latch bolt and internal moving parts. Check for any obstructions. Ensure mounting screws are not overtightened, which can bind the mechanism. |
| Låsebolten trækkes ikke helt ind. | Misalignment of the lever assembly or deadlatch, debris in the mechanism. | Check that the lever assemblies are properly aligned and securely fastened. Clean any visible debris. Lubricate the latch mechanism. |
| Døren låser ikke ordentligt. | Misaligned strike plate or latch bolt, worn latch bolt. | Adjust the strike plate position on the door frame to ensure proper engagement with the latch bolt. Inspect the latch bolt for wear; if severely worn, replacement may be necessary. |
| Lever set feels loose on the door. | Løse monteringsskruer. | Tighten all mounting screws. Do not overtighten. |
9. Garanti og support
For warranty information, technical support, or replacement parts, please contact Cal-Royal Products, Inc. directly. Refer to the product packaging or the official Cal-Royal website for current contact details and warranty terms.
Fabrikant: Cal-Royal Products, Inc.
Model: CR-SL50-26D
ASIN: B0789N3CDW
