EXTOL PREMIUM 125mm 900W Angle Grinder User Manual

1. Vigtige sikkerhedsinstruktioner

Læs alle sikkerhedsadvarsler, instruktioner, illustrationer og specifikationer, der følger med dette elværktøj. Undladelse af at følge alle instruktionerne nedenfor kan resultere i elektrisk stød, brand og/eller alvorlig personskade.

• Brug altid passende personlige værnemidler (PPE), herunder sikkerhedsbriller, høreværn, handsker og støvmaske.
• Sørg for, at arbejdsemnet er sikkert klampfør du påbegynder nogen form for operation.
• Keep hands clear of rotating parts and the cutting/grinding disc.
• Frakobl værktøjet fra strømkilden, før du foretager justeringer, skifter tilbehør eller udfører vedligeholdelse.
• The paddle switch design enhances safety by automatically shutting off the tool if the hand is removed or if the tool is dropped.
• Brug ikke værktøjet i eksplosive atmosfærer, såsom i nærheden af ​​brændbare væsker, gasser eller støv.
• Hold børn og omkringstående væk, mens du betjener et elværktøj.

2. Produktet er slutview og komponenter

The EXTOL PREMIUM Angle Grinder is designed for cutting and abrasive work on various materials. Its compact dimensions facilitate comfortable operation, even in confined spaces.

Figur 1: Hoved view of the EXTOL PREMIUM Angle Grinder, showing the motor housing, gear head, disc guard, and side handle attachment point.

Nøglekomponenter:

• Padlekontakt: Located on the main body, this safety switch requires continuous pressure to operate and automatically cuts power when released.
• Sidehåndtag: Provides additional grip and control during operation. Can be attached to either side of the gear head.
• Skivebeskytter: Protects the user from sparks, debris, and accidental contact with the rotating disc. It must always be in place and properly adjusted.
• Spindellåseknap: Bruges til at låse spindlen for nemt skiveskift.
• Slibe-/skæreskive: The consumable accessory used for material removal or cutting. (Not included with all models).

3. Opsætning

3.1 Montering af sidehåndtaget

The side handle can be screwed into either the left or right side of the gear head, depending on user preference and application. Ensure it is tightened securely before use.

Figur 2: Illustration of the side handle being screwed into one of the two available mounting points on the grinder's gear head.

3.2 Mounting/Changing Grinding/Cutting Discs

1. Afbryd strømmen: Always unplug the angle grinder from the power source before changing discs.
2. Press Spindle Lock: Tryk på spindellåseknappen og hold den nede for at forhindre spindlen i at rotere.
3. Loosen Flange Nut: Use the provided spanner wrench to loosen and remove the outer flange nut.
4. Fjern disk: Carefully remove the old disc.
5. Install New Disc: Place the new disc onto the inner flange, ensuring it is centered. The disc should fit snugly.
6. Secure Flange Nut: Replace the outer flange nut and tighten it firmly with the spanner wrench while holding the spindle lock button. Do not overtighten.

Figur 3: View of the angle grinder's spindle assembly with the disc and outer flange removed, illustrating the components involved in disc attachment.

3.3 Adjusting the Disc Guard

The disc guard should always be adjusted to provide maximum protection for the user, directing sparks and debris away from the body. Loosen the guard's clamping screw, rotate the guard to the desired position, and then securely tighten the screw.

4. Betjeningsvejledning

4.1 Tænd og sluk

• At tænde: Plug the tool into a suitable power outlet. Grip the tool firmly with both hands. Press and hold the paddle switch located on the underside of the tool's body. The tool will start.
• At slukke: Release the paddle switch. The tool will immediately stop. This safety feature prevents accidental startup and ensures the tool stops if dropped or if grip is lost.

4.2 Proper Grip and Control

Always hold the angle grinder firmly with both hands, one on the main body and the other on the side handle. Maintain a balanced stance and ensure stable footing.

Figur 4: A user demonstrating the correct two-handed grip on the EXTOL PREMIUM Angle Grinder, utilizing the main body and the side handle for optimal control.

4.3 Cutting and Grinding Techniques

• Starter: Lad skiven nå fuld hastighed, før den berører emnet.
• Skæring: Apply light, consistent pressure. Do not force the tool. Use the edge of the cutting disc.
• Slibning: Hold the disc at a slight angle (typically 15-30 degrees) to the workpiece. Move the tool smoothly across the surface.
• Undgå tilbageslag: Be aware of potential kickback, especially when cutting. Avoid binding the disc in the cut.
• Køling: Ved længere tids brug skal værktøjet køle af med jævne mellemrum for at forhindre overophedning.

5. Vedligeholdelse

Regelmæssig vedligeholdelse sikrer din vinkelslibers lange levetid og sikker drift.

• Rensning: After each use, clean the tool with a dry cloth. Use compressed air to clear dust from ventilation openings. Do not use water or chemical cleaners.
• Ledningsinspektion: Regularly inspect the power cord for any damage, cuts, or fraying. Replace damaged cords immediately.
• Udskiftning af børste: Carbon brushes (if applicable to this model) should be checked periodically and replaced when worn down to their limit marks. Refer to a qualified service technician for this procedure if unsure.
• Opbevaring: Opbevar værktøjet et tørt og sikkert sted, utilgængeligt for børn.

6. Fejlfinding

Dette afsnit omhandler almindelige problemer, du kan støde på med din vinkelsliber.

• Værktøjet starter ikke:
  • Kontroller, om netledningen er sat ordentligt i en fungerende stikkontakt.
  • Ensure the paddle switch is fully depressed.
  • Kontroller, at afbryderen ikke er udløst.
• Overdreven vibration:
  • Check if the grinding/cutting disc is properly installed and tightened.
  • Undersøg skiven for skader eller ubalance; udskift om nødvendigt.
  • Ensure the side handle is securely fastened.
• Reduceret ydeevne:
  • The disc may be worn or dull; replace it.
  • Sørg for at den korrekte type skive bruges til materialet.
  • Check for excessive dust buildup in the ventilation slots.

Hvis problemerne fortsætter, skal du kontakte en kvalificeret servicetekniker eller producentens support.

7. Specifikationer

8. Garanti og support

For detailed warranty information, please refer to the warranty card included with your product or visit the official Extol Premium webwebstedet. Behold din købskvittering som købsbevis.

For technical support, spare parts, or service inquiries, please contact your local Extol Premium dealer or the customer service department listed on the manufacturer's webwebsted.
