Pro-Ject Essential III Recordmaster Turntable User Manual

1. Introduktion

Thank you for choosing the Pro-Ject Essential III Recordmaster Turntable. This high-quality record player is designed to deliver exceptional audio performance with the convenience of integrated speed control, a built-in phono stage, and a USB output for digital recording. This manual provides comprehensive instructions for the proper setup, operation, maintenance, and troubleshooting of your new turntable. Please read it carefully before use to ensure optimal performance and longevity of your device.

Figure 1: Pro-Ject Essential III Recordmaster Turntable (White)

This image shows the Pro-Ject Essential III Recordmaster turntable in its white finish, featuring the platter, tonearm, and the "ESSENTIAL" branding on the plinth. The turntable is ready for operation.

2. Opsætning og montering

2.1 Udpakning og indhold

Carefully remove all components from the packaging. Please retain the original packaging for future transport or service.

Pakken skal indeholde:

• Pro-Ject Essential III Recordmaster Turntable
• Ortofon cartridge (pre-mounted)
• Tonearm
• RCA-lydkabel
• Strømforsyning
• Drivrem
• Platter
• Filtmåtte
• Støvdæksel

2.2 Placering

Place the turntable on a stable, level surface, away from direct sunlight, heat sources, and strong vibrations. Ensure adequate ventilation around the unit.

2.3 Monteringstrin

1. Installer tallerkenen: Carefully place the main platter onto the spindle. Ensure it sits securely and rotates freely.
2. Installer drivremmen: Locate the drive belt. Gently stretch the belt around the sub-platter (if applicable) and around the motor pulley. Ensure the belt is seated correctly in the groove of the motor pulley and is not twisted.
3. Install the Felt Mat: Læg filtmåtten oven på fadet.
4. Tonearm Setup:
   • Modvægt: Slide the counterweight onto the rear of the tonearm. Rotate it until the tonearm is balanced horizontally (floating freely). Lock the counterweight in place.
   • Sporingskraft: Refer to your cartridge's recommended tracking force (typically 1.5g - 2.0g for the Ortofon OM 10). Adjust the counterweight to the specified tracking force using the scale on the counterweight.
   • Anti-skøjteløb: Fastgør anti-skate-vægten til den lille løkke på tonearmsstøtten, og før tråden over anti-skate-trådstøtten. Anti-skate-kraften skal generelt svare til sporingskraften.


     Figure 2: Tonearm with Anti-Skate Weight

     Dette billede giver et nærbillede view of the tonearm, highlighting the anti-skate mechanism with its small hanging weight, which helps to balance the forces acting on the stylus during playback.
5. Installer støvdæksel: Carefully place the dust cover onto the hinges at the rear of the turntable.


   Figure 3: Turntable with Dust Cover Installed

   This image displays the Pro-Ject Essential III Recordmaster turntable with its clear dust cover in place, protecting the components from dust and debris.

2.4 Forbindelser

The Essential III Recordmaster features both RCA analog outputs and a USB digital output.

• RCA lydudgang: Connect the supplied RCA cable from the "L" (left) and "R" (right) outputs on the turntable to a line-level input (e.g., AUX, CD, Tuner) on your amplifier or active speakers. Since the turntable has a built-in phono stage, you do not need a dedicated "Phono" input on your amplivligere.
• USB-udgang: Connect a USB cable (not supplied) from the "OUT USB" port on the turntable to a free USB port on your computer (PC or Mac) for digital recording of your vinyl.
• Strømtilslutning: Connect the power adapter to the "DC IN" socket on the turntable and then plug it into a suitable wall outlet.

Figur 4: Tilslutninger på bagpanelet

This image displays the rear connection panel of the turntable, showing the USB output port, the grounding terminal, and the left (L) and right (R) RCA audio output jacks.

3. Betjeningsvejledning

3.1 Tænd/sluk

To power on the turntable, press the power button located on the plinth. The platter will begin to rotate. Press the button again to power off the unit.

3.2 hastighedsvalg

The Essential III Recordmaster supports 33 1/3 RPM and 45 RPM playback speeds.

• To switch between 33 1/3 RPM and 45 RPM, press the speed selection button located next to the power button. The corresponding LED indicator will illuminate.
• For 78 RPM records, a special pulley and stylus are required (not included). Consult your dealer for more information on 78 RPM playback.

3.3 Afspilning af en plade

1. Place a record on the platter, ensuring it is centered on the spindle.
2. Løft tonearmen ved hjælp af cue-håndtaget.
3. Placer forsigtigt tonearmen over den ønskede startrille på pladen.
4. Sænk forsigtigt tonearmen ved hjælp af cue-håndtaget. Pennen vil synke ned på pladen, og afspilningen vil begynde.
5. At the end of the record, lift the tonearm using the cueing lever and return it to the tonearm rest. Secure it with the tonearm clip.

3.4 USB-optagelse

The integrated USB output allows you to digitize your vinyl collection.

1. Connect the turntable to your computer via the USB cable.
2. Installer passende lydoptagelsessoftware på din computer (f.eks. Audacity, som er tilgængelig gratis online).
3. Select the turntable as the audio input device within your recording software settings.
4. Start playback on the turntable and begin recording in your software.
5. Follow your software's instructions for editing, saving, and exporting your digitized audio files.

4. Vedligeholdelse

4.1 Rengøring

• Turntable Plinth and Dust Cover: Use a soft, lint-free cloth to wipe the surfaces. For stubborn marks, a slightly damp en tør klud kan bruges. Undgå slibende rengøringsmidler eller opløsningsmidler.
• Platter and Felt Mat: The platter can be wiped with a dry cloth. The felt mat can be gently brushed to remove dust.
• Stylus: Use a dedicated stylus cleaning brush or fluid (available from audio retailers) to gently clean the stylus. Always brush from back to front.

4.2 Udskiftning af rem

The drive belt is a wear item and may need replacement over time if you notice inconsistent speed or slippage. Contact your dealer for a replacement belt. Installation involves carefully stretching the new belt around the sub-platter and motor pulley, similar to the initial setup.

5. Fejlfinding

If you encounter issues with your turntable, please consult the following table before contacting support.

6. Specifikationer

7. Garanti og support

For warranty information and technical support, please refer to the warranty card included with your product or visit the official Pro-Ject Audio Systems website. You can also contact your authorized Pro-Ject dealer for assistance.
