Brugermanual til trådløs vejrstation

Indledning

The Houzetek S657 Wireless Weather Station is designed to provide accurate indoor and outdoor temperature and humidity readings, along with a color display for weather forecasts, time, and alarm functions. This manual provides detailed instructions for setup, operation, and maintenance of your weather station.

Pakkens indhold

• Houzetek S657 Main Weather Station Unit
• Trådløs udendørs sensor
• USB strømkabel
• Brugermanual
• Note: AC adapter and 3 x AAA batteries for the main unit, and 2 x AAA batteries for the outdoor sensor are not included.

Produkt overview

Familiarize yourself with the main components and display features of your Houzetek S657 Weather Station.

Figur 1: Front view of the Houzetek S657 Wireless Weather Station, showing the color display with indoor and outdoor temperature and humidity, weather forecast icons, time, and date.

Figur 2: Detailed diagram of the weather station's display and control buttons. Key features include:

• B1: Color forecast icons with comfort level display
• B2: Indoor temperature (°F / °C)
• B3: Indoor humidity (%RH)
• B4: Hour and date (month/day/year)
• B5: Outdoor temperature (°F / °C)
• B6: Outdoor humidity (%RH)
• B7: Max/min temperature alert

Top buttons (from left to right): DOWN, MODE, SNOOZE/LIGHT, CHANNEL, UP, ALERTS, ALARM.

Figur 3: Tilbage view of the weather station illustrating the three power options: USB Port, AC Adapter (output: 5V, 1.2A), and 3 x AAA Batteries (not included).

Figur 4: The weather station offers two ways to stand: integrated keyholes for wall mounting and a supporting stand for desktop placement.

Opsætning

1. Strømforsyning til hovedenheden

1. Brug af USB-strøm: Connect the provided USB power cable to the DC 5V port on the back of the main unit. Plug the other end into a USB power adapter (not included) or a compatible USB port.
2. Brug af batterier: Open the battery compartment on the back of the main unit. Insert 3 x AAA batteries (not included) according to the polarity markings (+/-). The display will light up.
3. Note: For continuous display backlight, USB power is recommended. Batteries primarily serve as a backup for settings during power outages.

2. Installation af batterier til udendørssensorer

1. Åbn batterirummet på udendørssensoren.
2. Isæt 2 x AAA-batterier (medfølger ikke) i henhold til polaritetsmarkeringerne (+/-).
3. Luk batterirummet forsvarligt.

3. Parring af udendørssensoren

The main unit will automatically search for the outdoor sensor upon initial power-up. The outdoor temperature and humidity section on the display will show "--.--" or flashing readings until a connection is established.

• Ensure both the main unit and the outdoor sensor have fresh batteries or are powered.
• Place the outdoor sensor within 3 meters of the main unit during the initial pairing process.
• If the connection is not established within 3 minutes, press and hold the "CHANNEL" button on the main unit for 3 seconds to manually initiate a search.
• Once connected, the outdoor temperature and humidity will be displayed.

Figur 5: The weather station main unit and its wireless outdoor sensor, illustrating the effective transmission range of up to 99 meters in open areas.

4. Indledende indstillinger (tid, dato, enheder)

After successful sensor pairing, set the time, date, and preferred temperature units.

1. Press the "MODE" button to cycle through display modes (Time, Alarm, Date).
2. Indstilling af tid/dato: When the time is displayed, press and hold the "MODE" button for 3 seconds to enter time setting mode. The hour will flash. Use "UP" or "DOWN" buttons to adjust, then press "MODE" to confirm and move to the next setting (minute, year, month, day).
3. Setting Temperature Units: In normal display mode, press the "UP" button to switch between Celsius (°C) and Fahrenheit (°F).

Betjeningsvejledning

Viewtemperatur og luftfugtighed

• The main display continuously shows indoor temperature and humidity (B2, B3) and outdoor temperature and humidity (B5, B6).
• The comfort level indicator (B1) provides a visual representation of indoor comfort based on temperature and humidity.

Indstilling af alarm

1. Press the "MODE" button until the alarm time is displayed.
2. Press and hold the "ALARM" button for 3 seconds. The alarm hour will flash.
3. Use "UP" or "DOWN" to adjust the hour, then press "ALARM" to confirm and move to minutes.
4. Adjust minutes with "UP" or "DOWN", then press "ALARM" to confirm.
5. Press "ALARM" again to toggle the alarm ON/OFF. An alarm icon will appear on the display when activated.

Snooze- og baggrundsbelysningsfunktion

• When the alarm sounds, press the "SNOOZE/LIGHT" button to activate the snooze function. The alarm will sound again after approximately 5 minutes.
• Press any other button to stop the alarm for the day.
• Press the "SNOOZE/LIGHT" button at any time to temporarily illuminate the display backlight (if powered by batteries). If powered by USB, the backlight is continuously on.

Max/Min Temperature and Humidity Records

• Press the "ALERTS" button repeatedly to view the maximum and minimum recorded indoor and outdoor temperature and humidity values.
• To clear the recorded Max/Min values, press and hold the "ALERTS" button for 3 seconds while viewved dem.

Opretholdelse

Udskiftning af batteri

• When the battery indicator appears on the display, replace the batteries in the main unit or outdoor sensor as needed.
• Always replace all batteries in a set with new ones of the same type.
• Bortskaf gamle batterier ansvarligt i henhold til lokale regler.

Rensning

• Tør enheden og sensoren af ​​med en blød kludamp klæde.
• Brug ikke slibende rengøringsmidler eller opløsningsmidler, da de kan beskadige displayet ellerasing.
• Ensure no water enters the battery compartments or electronic components.

Fejlfinding

Specifikationer

Garanti og support

For warranty information and technical support, please refer to the contact details provided on the product packaging or the official Houzetek webwebsted. Gem din købskvittering som købsbevis i tilfælde af garantikrav.
