Brandt Fagor IF3S strømmodul (AS0021115) brugsanvisning

1. Introduktion

This manual provides important information regarding the Brandt Fagor IF3S Power Module, model number AS0021115. This power module is a critical component designed for various kitchen appliances, including ovens, cookers, induction hobs, and ceramic hobs from brands such as Dietrich, Sauter, Brandt, Fagor, Smeg, Mastercook, Thomson, Asko, Blanco, CDA, Orinier, Thermor, Beko, Caple, Etna, and Gorenje.

The module is identified by part numbers AS0021115 and 691651673. It is also compatible with specific device models, including 3MF-2IS3-E, 803HI1632072, 803HI1632271, 803HI163227272, 803HI166111, 803HI166112, 803HI166211, 803HI166212, 803HI183271, 803HI183272, 803HI18611, 803HI186112, 803HI186211, 902010002, 902010010, and 902016447.

2. Sikkerhedsoplysninger

ADVARSEL: Installation and servicing of this power module should only be performed by a qualified technician. Improper installation can lead to electrical shock, fire, or damage to the appliance.

• Always disconnect the appliance from the main power supply before attempting any installation, repair, or maintenance.
• Ensure all connections are secure and correctly wired according to the appliance's specific service manual.
• Do not operate the appliance if the power module or any associated wiring appears damaged.
• Keep children and pets away from the appliance during installation and repair.

3. Opsætning og installation

This power module is a replacement part for specific kitchen appliances. Installation typically involves replacing an existing faulty module. Due to the complexity and electrical nature of this component, professional installation is strongly recommended.

1. Forberedelse: Ensure the appliance is completely disconnected from the power supply. Refer to the appliance's service manual for specific disassembly instructions.
2. Adgang: Carefully open the appliance to gain access to the existing power module.
3. Fjernelse: Disconnect all wiring from the old module, noting their positions for correct re-connection. Remove any mounting screws or clips securing the old module.
4. Installation: Position the new Brandt Fagor IF3S Power Module (AS0021115) in place. Secure it with the appropriate screws or clips.
5. Ledningsføring: Reconnect all wiring to the new module, ensuring each connection matches the original configuration. Double-check all connections for security and correctness.
6. Reassembly & Test: Carefully reassemble the appliance. Before full operation, perform a preliminary test as per the appliance's service manual to ensure proper function and safety.

Figur 1: Øverst view of the Brandt Fagor IF3S Power Module (AS0021115). This image displays the main circuit board, several large capacitors, and a metal heat sink assembly on top, with various electrical connections visible.

Figur 2: Nederst view of the Brandt Fagor IF3S Power Module (AS0021115). This perspective shows the underside of the circuit board and a cooling fan integrated into the module's base, essential for thermal management.

4. Betjening

The Brandt Fagor IF3S Power Module is an internal component that facilitates the proper functioning of your appliance. It does not have user-operable controls. Once correctly installed, its operation is integrated with the appliance's normal functions. Ensure the appliance is used according to its own user manual.

5. Vedligeholdelse

As an internal electronic component, the power module itself requires no routine user maintenance. Any maintenance or inspection should be part of a professional service of the appliance it is installed in.

• Ensure the appliance's ventilation pathways are clear to prevent overheating, which can affect the power module's lifespan.
• If the appliance exhibits unusual behavior (e.g., power fluctuations, error codes related to power), consult a qualified technician.

6. Fejlfinding

Troubleshooting issues related to a power module typically requires diagnostic tools and expertise. If your appliance is not functioning correctly after a power module replacement, or if you suspect the module is faulty, consider the following:

• Ingen strøm: Check the main power supply to the appliance and ensure all internal connections to the power module are secure.
• Intermitterende drift: This could indicate a loose connection or a failing component within the module. Professional inspection is advised.
• Fejlkoder: Refer to your appliance's specific user or service manual for interpretation of error codes, as some may point to power supply issues.
• Overophedning: Ensure adequate ventilation around the appliance. If the module itself feels excessively hot (only check if safe to do so and power is disconnected), it may indicate a fault or an issue with the appliance's cooling system.

For all complex issues, contact a certified appliance repair technician.

7. Specifikationer

8. Garanti og support

All items sold benefit from the legal guarantee of conformity and the guarantee against hidden defects. For specific warranty claims or technical support, please refer to the original point of purchase or the manufacturer of the appliance in which this module is installed.

Det anbefales at gemme dit købsbevis af garantihensyn.
