Microlife Blood Pressure Monitor BP A2 BASIC User Manual

Indledning

This manual provides essential information for the safe and effective use of your Microlife BP A2 BASIC Blood Pressure Monitor. Please read it thoroughly before first use and keep it for future reference.

The Microlife BP A2 BASIC is a fully-automatic upper arm blood pressure monitor designed for accurate and comfortable blood pressure measurement at home. It features PAD technology for early recognition of heart arrhythmias.

Nøglefunktioner:

• Gentle+ Technology: Ensures gentle inflation and deflation for comfortable measurements.
• PAD Technology: Detects pulse arrhythmia for early recognition of irregular heartbeats.
• Bred rækkevidde manchet: Fan-shaped cuff (22-42 cm) designed for better fitting and accuracy.
• Automatisk drift: Fully automatic measurement process.
• 5-Year International Manufacturer Warranty: Provides long-term assurance for your device.

Opsætning

Udpakning og komponenter:

Your Microlife BP A2 BASIC package should contain the following items:

• 1x Microlife BP A2 BASIC Blood Pressure Monitor unit
• 1x Upper Arm Cuff (22-42 cm)
• 4x AA batterier
• 1x vekselstrømsadapter
• 1x Brugsanvisning (dette dokument)
• 1x opbevaringspose

Strømforsyning til enheden:

The monitor can be powered by batteries or the included AC adapter.

Batteri installation:

1. Åbn batterirummets dæksel på bagsiden af ​​enheden.
2. Insert four new AA batteries, ensuring correct polarity (+ and -).
3. Luk batterirummets dæksel forsvarligt.

AC-adaptertilslutning:

1. Insert the adapter plug into the DC port on the side of the monitor.
2. Sæt AC-adapteren i en almindelig stikkontakt.
3. When using the AC adapter, batteries are not required but can remain in the device.

Manchetforbindelse:

1. Insert the air tube connector firmly into the air socket on the left side of the monitor.
2. Ensure the cuff is properly connected before taking a measurement.

Betjeningsvejledning

Før måling:

• Avoid eating, smoking, or exercising for at least 30 minutes before measurement.
• Rest for 5-10 minutes in a quiet environment before taking a reading.
• Sid behageligt med ryggen støttet og fødderne fladt på gulvet.
• Placer din arm på en flad overflade, så manchetten er i hjertehøjde.
• Ensure the cuff is applied directly to the bare skin of your upper arm, not over clothing.

Påføring af manchetten:

1. Slide the open end of the cuff through the metal ring to form a loop. The smooth cloth should be on the inside of the cuff loop.
2. Place the cuff on your left upper arm so the air tube points towards your forearm.
3. The bottom edge of the cuff should be approximately 2-3 cm above your elbow.
4. Tighten the cuff evenly around your arm using the hook-and-loop fastener. It should be snug but not too tight (you should be able to fit two fingers under the cuff).
5. Ensure the artery mark on the cuff (if present) is aligned with your brachial artery.

Foretag en måling:

1. Tryk på ON/OFF-knappen for at starte målingen.
2. The monitor will automatically inflate the cuff. The Gentle+ technology ensures a comfortable inflation.
3. Forbliv stille og tavs under målingen.
4. Once the measurement is complete, the systolic, diastolic, and pulse readings will be displayed on the screen.
5. If PAD technology detects an irregular heartbeat, a corresponding symbol will appear on the display.
6. Press the ON/OFF button again to turn off the monitor, or it will automatically shut off after approximately 1 minute.

Understanding Your Readings:

• SYS (Systolisk tryk): Det øverste tal, der angiver trykket i dine arterier, når dit hjerte slår.
• DIA (diastolisk tryk): Det nederste tal, der angiver trykket i dine arterier mellem slag.
• PUL (Pulsfrekvens): Din puls, målt i slag i minuttet.
• PAD Symbol: Indicates the detection of an irregular heartbeat. Consult your doctor if this symbol appears frequently.

Hukommelsesfunktion:

The Microlife BP A2 BASIC stores previous measurements. Press the 'M' button to recall stored readings. Refer to the on-screen indicators for navigation.

Opretholdelse

Rensning:

• Clean the monitor unit and cuff with a soft, dry cloth.
• For stubborn stains, use a cloth lightly dampafsluttes med vand eller et mildt rengøringsmiddel.
• Do not use abrasive cleaning agents, alcohol, or solvents.
• Do not immerse the monitor or cuff in water.

Opbevaring:

• Store the device in its original storage bag in a cool, dry place, away from direct sunlight and extreme temperatures.
• Hvis enheden ikke skal bruges i længere tid, skal batterierne fjernes for at forhindre lækage.

Fejlfinding

Almindelige problemer og løsninger:

If problems persist, please contact Microlife customer support or your local distributor.

Specifikationer

• Model: BPA2-B / A2 BASIC+A
• Dimensioner: Cirka 14 x 6 x 8 cm
• Vægt: Cirka 340 gram (inklusive batterier)
• Målemetode: Oscillometrisk
• Måleområde: Blood Pressure: 20-280 mmHg; Pulse: 40-200 beats/minute
• Manchetstørrelse: 22-42 cm (Fan Shape Wide Range Cuff)
• Strømkilde: 4 x 1.5 V AA batteries or DC 6V, 600 mA AC adapter
• Driftsbetingelser: 10-40 °C (50-104 °F) / 15-95 % relative humidity non-condensing
• Opbevaringsbetingelser: -20-+55 °C (-4-+131 °F) / 15-95 % relative humidity non-condensing
• Hukommelse: 30 Data memory
• Teknologi: Gentle+, PAD (Pulse Arrhythmia Detection)

Garanti og support

Your Microlife BP A2 BASIC Blood Pressure Monitor comes with a 5-Year International Manufacturer Warranty fra købsdatoen. Gem venligst din købskvittering som købsbevis.

This warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized repairs, or failure to follow the instructions in this manual.

For warranty claims, technical support, or service inquiries, please contact your local Microlife distributor or visit the official Microlife webwebsted for kontaktoplysninger.

Important: Self-treatment based on blood pressure measurements is dangerous. Always consult your doctor for diagnosis and treatment.
