EcoSmart ECOMINI6 Elektrisk Mini Tank Vandvarmer Brugsanvisning

1. Produktet er slutview

The EcoSmart ECOMINI6 Electric Mini Tank Water Heater is designed to provide hot water efficiently at the point of use. Its compact design allows for installation in various locations, such as under sinks or in small utility rooms. This unit can serve as a primary hot water source for a single faucet or as a booster for an existing hot water system, reducing wait times for hot water.

Nøglefunktioner:

• Sleek and compact design with digital output temperature display.
• 99.8% energy efficient.
• Fremstillet i USA.
• Operates on 12 Amps.

2. Sikkerhedsoplysninger

Please read and understand all instructions before installing or operating this water heater. Failure to follow these instructions could result in property damage, serious injury, or death.

• Elektrisk sikkerhed: Ensure the unit is connected to a properly grounded 110-volt outlet. Do not use extension cords. Disconnect power before performing any maintenance or service.
• Vandtryk: Do not operate the unit if the water supply is off or if the unit is not completely filled with water.
• Temperatur: Hot water can cause severe burns. Exercise caution when setting the temperature and using hot water.
• Installation: Installation must be performed by a qualified plumber or technician in accordance with all local plumbing and electrical codes.
• Beliggenhed: Install the unit in a location where it is protected from freezing temperatures and where any potential leaks will not cause damage to the surrounding area.

3. Installation og opsætning

The EcoSmart ECOMINI6 is designed for easy installation. It can be mounted on a wall or placed on a flat surface. Ensure adequate space for plumbing connections and ventilation.

3.1 Montering

The unit is lightweight and can be wall-mounted using appropriate fasteners (not included) or placed on a sturdy, level surface. Ensure the mounting location can support the weight of the unit when full of water (approximately 24.9 lbs dry + 6 gallons * 8.34 lbs/gallon = ~75 lbs).

3.2 VVS-tilslutninger

Connect the cold water supply to the inlet pipe and the hot water outlet to the fixture. The unit requires a single water line connection. For booster applications, connect the unit in-line with your existing hot water supply.

Billede 1: Side view of the EcoSmart ECOMINI6, illustrating the plumbing connections at the top and the electrical cord extending from the side. This view helps in understanding how the unit integrates into a plumbing system.

3.3 Elektrisk tilslutning

Plug the unit into a standard 110-volt electrical outlet. The unit draws 12 Amps. Ensure the circuit can handle this load.

Billede 2: Front view of the EcoSmart ECOMINI6, highlighting the main body, the EcoSmart logo, and the blue control panel with the temperature adjustment dial and indicator lights.

3.4 Indledende opstart

1. Sørg for, at alle VVS-forbindelser er sikre og lækagefri.
2. Open the hot water faucet at the point of use to allow air to escape from the tank.
3. Once water flows steadily from the faucet, close the faucet.
4. Plug the unit into the electrical outlet. The 'Power' indicator light will illuminate.
5. Adjust the temperature dial to your desired setting. The 'Heating' indicator light will illuminate when the unit is actively heating water.

3.5 Installationsvideo

For a visual guide on the EcoSmart Mini Tank Water Heater, please refer to the official product video:

4. Betjeningsvejledning

The EcoSmart ECOMINI6 is designed for simple operation.

4.1 Temperaturjustering

The temperature of the water can be adjusted using the dial located on the front of the unit. Rotate the dial clockwise to increase the temperature and counter-clockwise to decrease it. Start with a moderate setting and adjust as needed to avoid excessively hot water.

4.2 Indikatorlys

• Strømlys: Illuminates when the unit is plugged in and receiving electrical power.
• Opvarmningslys: Illuminates when the unit's heating element is active and heating the water. It will turn off once the set temperature is reached.

5. Vedligeholdelse

Regelmæssig vedligeholdelse sikrer optimal ydeevne og levetid for din vandvarmer.

• Skylning af tanken: Periodically flush the tank to remove sediment buildup. This frequency depends on your water quality. Turn off power and water supply, then drain the tank.
• Inspektion: Regularly inspect the unit for any signs of leaks, corrosion, or damage to the power cord.
• Rensning: Rengør ydersiden af ​​enheden med en blød, damp klæde. Brug ikke slibende rengøringsmidler eller opløsningsmidler.

6. Fejlfinding

If you encounter issues with your EcoSmart ECOMINI6, refer to the following common troubleshooting steps:

• Intet varmt vand: Check if the unit is plugged in and the 'Power' light is on. Ensure the circuit breaker has not tripped. Verify the water supply is open.
• Vandet er ikke varmt nok: Adjust the temperature dial to a higher setting. Allow sufficient time for the water to heat.
• Lækager: Turn off the water supply and power immediately. Inspect all plumbing connections for tightness. If leaks persist, contact a qualified plumber.
• Lavt vandtryk: Check the water supply valve to ensure it is fully open. Inspect the faucet aerator for clogs.

For persistent issues, contact EcoSmart customer support.

7. Specifikationer

8. Garanti og support

The EcoSmart ECOMINI6 Electric Mini Tank Water Heater comes with a warranty to ensure your peace of mind.

• Garantibeskrivelse: 6 years limited leaks / 2 year parts.

For technical support, warranty claims, or further assistance, please contact EcoSmart customer service. Refer to the product packaging or the official EcoSmart webhjemmeside for de seneste kontaktoplysninger.
