Premier TENS-maskine fra Med-Fit brugermanual

Indledning

This user manual provides comprehensive instructions for the safe and effective operation of your Premier TENS Machine by Med-Fit. This fully rechargeable dual-channel TENS and muscle stimulator is designed for pain relief, muscle strengthening, massage, and relaxation, featuring 30 pre-set programs.

The device is fully digital, offering effective and reliable treatment with a large LCD screen and user-friendly push buttons. A pause function allows for easy repositioning of electrodes. It also includes a power-saving feature that turns the unit off after 5 minutes of inactivity.

Image: The Premier TENS Machine unit shown with multiple electrode pads and the Med-Fit brand logo, indicating its primary function as a TENS and muscle stimulator.

Vigtige sikkerhedsoplysninger

Please read all instructions carefully before using the device. Improper use can lead to injury or ineffective treatment. Consult a healthcare professional before use, especially if you have pre-existing medical conditions, are pregnant, or have a pacemaker.

• Må ikke anvendes, hvis du har en pacemaker, implanteret defibrillator eller anden implanteret metallisk eller elektronisk enhed.
• Do not use on open wounds, rashes, swollen, red, infected, or inflamed skin areas.
• Do not use near the heart, over the carotid sinus nerves (front of the neck), or on the head.
• Opbevares utilgængeligt for børn.
• Discontinue use and consult a doctor if you experience adverse reactions.
• This device is for personal use and should not be shared.

Pakkens indhold

Når du åbner pakken, skal du kontrollere, at alle komponenter er til stede og ubeskadigede:

• Premier TENS Machine (Model EM-6300A)
• 16 Self-adhesive Electrode Pads
• Electrode Lead Wires (typically 2 sets for dual channel)
• USB opladningskabel
• AC Power Adapter (UK plug type shown in images)
• User Manual / Patient Guide to TENS
• Storage Pouch/Case (as indicated by blue case in image)

Image: The complete package contents including the TENS unit, electrode pads, lead wires, charging cable, AC adapter, and user guide, all neatly arranged.

Produkt overview

The Premier TENS Machine is a compact and robust device designed for ease of use. It features a large LCD screen displaying program information, intensity levels for two channels (CH1, CH2), and a treatment timer countdown.

Kontrol og display:

• LCD skærm: Displays program number, intensity levels (0-99), mode (TENS/EMS), and remaining treatment time.
• MODE knap: Cycles through the 30 pre-set programs.
• SET -knap: Confirms program selection or enters parameter adjustment mode.
• Up/Down Arrows (CH1 & CH2): Adjust intensity levels for each channel independently.
• Pause Button (%): Temporarily pauses the treatment, allowing for electrode repositioning.
• Power knap: Tænder/slukker enheden.
• Indikator for lavt batteri: Giver besked, når batteriet skal genoplades.

Image: A hand holding the compact Premier TENS Machine, demonstrating its portable size and ergonomic design, with the LCD screen and control buttons clearly visible.

Billede: Bagsiden view of the TENS machine, highlighting the sturdy metal belt clip for convenient portability during use.

Opsætning

1. Opladning af enheden:

The Premier TENS Machine is fully rechargeable. Before first use, ensure the device is fully charged. Connect the USB charging cable to the unit's charging port and plug the other end into the supplied AC power adapter or any standard USB power source (e.g., computer, printer USB port).

Image: The TENS machine connected via its USB cable to a wall charger, illustrating the charging process.

2. Connecting Electrodes:

1. Ensure the device is turned off before connecting or disconnecting electrodes.
2. Connect the electrode lead wires to the output ports on the top of the TENS unit (CH1 and CH2).
3. Attach the 2mm pin connectors of the lead wires to the self-adhesive electrode pads.
4. Peel the electrode pads from their protective liner.
5. Apply the electrode pads firmly to clean, dry skin in the desired treatment area. Refer to the "Electrode Placement" section for guidance.

Image: A detailed diagram illustrating the high-quality construction of the reusable self-adhesive electrodes, showing layers of flexible fabric, conductive carbon, and hypoallergenic gel, along with the 2mm pin connector.

Betjeningsvejledning

1. Tænd: Press the Power button to turn on the device. The LCD screen will illuminate.
2. Vælg program: Tryk på MODE button to cycle through the 30 pre-set programs. Each program is designed for specific therapeutic needs (TENS for pain relief, EMS for muscle stimulation, massage). Refer to the included Patient Guide for detailed program descriptions.
3. Bekræft program: Once the desired program is displayed, press the SÆT knappen for at bekræfte.
4. Juster intensitet: Brug Up (▲) og Ned (▼) arrow buttons for CH1 and CH2 independently to increase or decrease the intensity. Start with a low intensity and gradually increase until you feel a comfortable, strong, but not painful, sensation.
5. Pause funktion: During treatment, press the % button to pause the stimulation. This allows you to reposition electrodes or take a break without turning off the unit. Press it again to resume.
6. Behandlingstimer: The LCD displays a countdown timer for the selected program's duration. The unit will automatically turn off when the treatment is complete.
7. Sluk: Press and hold the Power button to turn off the device. Always turn off the unit before removing electrodes.

Elektrodeplacering

Correct electrode placement is crucial for effective and safe treatment. Always refer to the detailed electrode placement guides provided in your Patient Guide to TENS. General guidelines include:

• Place electrodes on clean, dry, intact skin.
• For pain relief, place electrodes around or directly on the painful area, ensuring they do not touch each other.
• For muscle stimulation, place electrodes on the belly of the muscle you wish to stimulate.
• Avoid placing electrodes over joints, bony prominences, or areas with excessive hair.
• Never place electrodes on the head, face, front of the neck, or directly over the heart.

Billede: Visuelt eksempelamples demonstrating various electrode placements on the body, including the back, knee, arm, and ankle, for targeted pain relief.

Vedligeholdelse og pleje

• Rengøring af enheden: Tør enheden af ​​med en blød, damp klud. Brug ikke slibende rengøringsmidler, og nedsænk ikke enheden i vand.
• Elektrodepleje: After each use, reattach the electrode pads to their protective liner to preserve their adhesive quality. Store them in a sealed bag to prevent drying. Replace electrodes when they lose their stickiness.
• Opbevaring: Store the device and accessories in a cool, dry place, away from direct sunlight and extreme temperatures. Use the provided storage pouch/case.
• Batteri: The device contains a rechargeable Lithium Ion battery. Do not attempt to replace the battery yourself.

Fejlfinding

Specifikationer

• Modelnummer: EM-6300A
• Kanaler: Dobbelt kanal
• Programmer: 30 Pre-set Programs (TENS, EMS, Massage)
• Strømkilde: Genopladeligt litium-ion-batteri (inkluderet)
• Opladning: USB (compatible with AC adapter and USB ports)
• Vægt: Approximately 750g (Package Weight: 839 Grams)
• Dimensioner: Pakkemål: 25.3 x 23.7 x 8.9 cm
• Fabrikant: The Tens Company
• Medical Compliance: Fully compliant to the medical device directive Class 2a, UK approved medical company.

Garanti og support

The Premier TENS Machine by Med-Fit comes with a 5-års garanti.

Med-Fit, as a UK approved medical company, provides full support and after-sales service. Professional advice is available from their experienced TENS therapy team. For any inquiries, technical assistance, or warranty claims, please contact the manufacturer directly using the contact information provided in your product packaging or on the Med-Fit official webwebsted.
