Viper 5706V 2-Way Car Security with Remote Start System User Manual

Indledning

The Viper 5706V Responder LC3 is a complete security and remote start system designed to provide comprehensive protection and convenience for your vehicle. Featuring a full one-mile range, the system includes a remote with easy-to-understand priority icons and a text screen on an LCD display. This allows for intuitive command and monitoring of your vehicle's status with simple, prioritized buttons. The five-button remote can control up to 24 different functions across two vehicles. It is also the slimmest display remote available, packed with advanced features. Beyond security, it offers remote start capabilities, including an Active Temp Check feature that displays the vehicle's interior temperature. The Runtime Reset function allows you to extend the remote start duration for optimal comfort. In the event of a security breach, the system will immediately notify you within range with Revenger siren tones.

Hvad er der i æsken

Your Viper 5706V system package includes the following components:

• Transmitter (LCD remote)
• Brain (Main control unit)
• Harness (Wiring for installation)
• Manual (User and installation guides)

Nøglefunktioner

• 2-Way Security + Remote Start System with 5-Button LCD Transmitter
• 5-button sidekick remote control transmitter
• 1 mile range for enhanced control and monitoring
• 4-Channel vehicle security system
• Door and trunk triggers for comprehensive protection
• LCD display with priority icons and text screen
• Active Temp Check to display vehicle interior temperature
• Runtime Reset for extending remote start duration
• Revenger siren tones for alarm notification

Specifikationer

Opsætning

Installation of the Viper 5706V system requires specialized knowledge of vehicle electrical systems and security wiring. For optimal performance and to ensure proper functionality, professional installation by an authorized Viper dealer or certified automotive electronics technician is highly recommended. Attempting self-installation without adequate experience may void your warranty and could lead to damage to your vehicle or the system.

Generel installation overståetview (Professional Recommended)

1. Komponentplacering: Strategically mount the main control unit (brain), siren, and antenna in secure and discreet locations within the vehicle.
2. Ledningsforbindelser: Connect the system's harness to the vehicle's electrical system, including power, ground, ignition, accessory, and starter wires. This step often requires identifying specific wires in the vehicle's factory wiring harness.
3. Sensor installation: Install various sensors such as shock sensors, door triggers, and trunk triggers to detect unauthorized entry or impact.
4. Bypass Module (If Required): For vehicles with factory immobilizers or transponder keys, a bypass module may be necessary to allow remote starting without the physical key. This module integrates with the vehicle's data bus.
5. Indledende programmering: After physical installation, the system and remotes must be programmed to the vehicle. This involves specific sequences of button presses and ignition cycles as detailed in the professional installation manual.

Always refer to the detailed installation manual provided with your system for precise wiring diagrams and programming steps, or consult with a professional installer.

Betjeningsvejledning

The Viper 5706V system comes with two remote controls: a 2-way LCD remote for feedback and a 1-way companion remote. Familiarize yourself with the buttons and their functions.

Fjernbetjening overview

Grundlæggende funktioner

• Lås/arm: Tryk på Låse button once to arm the security system and lock the vehicle doors. The LCD remote will display "LOCKED" and provide confirmation.
• Lås op/deaktiver: Tryk på Lås op button once to disarm the security system and unlock the vehicle doors. The LCD remote will display "OPEN" or "UNLOCKED" and provide confirmation.
• Fjernstart: Tryk og hold på Fjernstart button (often a circular arrow icon) for approximately 3 seconds. The vehicle will start, and the LCD remote will confirm "REMOTE START" or "START" and may display the runtime countdown. To turn off the engine remotely, press and hold the same button again.
• Trunk Release: Tryk og hold på Bagagerum button (often an open trunk icon or AUX button) for approximately 3 seconds to pop the vehicle's trunk. The LCD remote will display "TRUNK" or "OPEN".
• Paniktilstand: Tryk og hold på Låse og Lås op buttons simultaneously to activate the panic alarm. Press any button to turn it off.

Advanced Features (LCD Remote)

• Active Temp Check: When remote started, the LCD remote can display the interior temperature of your vehicle. Refer to the full manual for specific button sequences to activate this display.
• Runtime Reset: If your vehicle is running via remote start, you can extend the runtime by pressing a specific button combination (refer to manual). The LCD remote will update the remaining time.
• Alarmmeddelelser: The 2-way LCD remote provides instant feedback if the alarm is triggered, indicating which zone was violated (e.g., door open, shock sensor). It will display "ALARM" and the specific trigger.
• Statuskontrol: Pressing a specific button (often the 'F' or function button) can provide a status update on the vehicle, such as armed/disarmed status, door open/closed, and battery level.

For a complete list of functions and detailed instructions, please refer to the comprehensive user manual included with your Viper 5706V system.

Opretholdelse

Proper maintenance ensures the longevity and reliable operation of your Viper 5706V system.

• Ekstern udskiftning af batteri: The 2-way LCD remote uses CR2 batteries. Monitor the battery indicator on the remote's display. When the battery is low, replace it promptly to ensure consistent communication and prevent the remote from going out of sync with the system. A top customer review notes that a low battery, even if the LCD still displays, can cause the unit to get out of sync. Regular charging or replacement is recommended.
• Rensning: Keep the remote controls and the system's main unit clean and free from dust and debris. Use a soft, dry cloth for cleaning. Avoid using harsh chemicals or abrasive materials.
• Antenneplacering: Ensure the system's antenna is not obstructed or damaged, as this can affect the remote's range.
• Professionelle tjek: Consider having your system professionally inspected periodically, especially if you notice any changes in performance or functionality.

Fejlfinding

If you encounter issues with your Viper 5706V system, consider the following common troubleshooting steps:

• Fjernbetjeningen reagerer ikke:
  • Check the remote's battery level. Replace or recharge the battery if it's low.
  • Ensure you are within the system's operating range (up to 1 mile). Obstacles like buildings or hills can reduce range.
  • If the remote is out of sync (as noted by some users), try disconnecting and reconnecting the main brain unit's power connections (professional assistance recommended for this step).
• Vehicle Not Remote Starting:
  • Ensure the vehicle is in neutral (for manual transmissions, if configured) or park (for automatics) and the parking brake is engaged.
  • Check if the hood is closed properly. Many systems have a hood pin safety switch.
  • Verify that the vehicle's battery is charged.
  • If a bypass module is installed, ensure it is functioning correctly.
• Alarmudløsning tilfældigt:
  • Adjust the sensitivity of the shock sensor. This usually involves a dial on the sensor itself.
  • Check all door, hood, and trunk pins to ensure they are making proper contact when closed.
  • Ensure no loose items are rattling inside the vehicle that could trigger the shock sensor.

For persistent issues or complex problems, it is highly recommended to contact a professional installer or Viper customer support.

Garanti & Support

Juridisk ansvarsfraskrivelse: Sound Security Online is not affiliated with Viper nor do they represent themselves as their authorized distributor. Merchandise offered in this website is strictly parallel merchandise and carries Sound Security Online warranty only. Their name and trademark is for trademark recognition purpose only. Sound Security Online is not using logo nor they intent to free ride on their trademark.

Please note that the warranty for your Viper 5706V system may be dependent on whether it was purchased and installed by an authorized retailer. Always review the specific warranty information provided with your product at the time of purchase.

For technical support, product inquiries, or to locate an authorized installer, please visit the official Viper website or contact their customer service department directly. Contact information can typically be found in the product packaging or on the manufacturer's official webwebsted.
