1. Introduktion

This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Modine HD45AS0111 Natural Gas Hot Dawg Garage Heater. This unit is designed to provide reliable heating for garages and workshops, offering 45,000 BTU with an 80% efficiency rating. Please read this manual thoroughly before attempting any installation or operation.

Figure 1: Modine HD45AS0111 Natural Gas Hot Dawg Garage Heater. This image shows the front and side view of the grey-colored unit heater, featuring the 'Hot Dawg' logo and adjustable louvers for heat distribution.

Nøglefunktioner:

• Stille drift
• Certified for residential, commercial, and industrial use
• Lav profile design and neutral color
• Installs quickly and easily with field wiring connections and knockouts for quick access to gas and electricity
• Standard power exhaust simplifies side-wall or roof venting with small-diameter vent pipe

2. Sikkerhedsoplysninger

ADVARSEL: Forkert installation, justering, ændring, service eller vedligeholdelse kan forårsage skade på ejendom, personskade eller død. Læs installations-, betjenings- og vedligeholdelsesinstruktionerne grundigt, før du installerer eller servicerer dette udstyr.

This product can expose you to chemicals including carbon monoxide, which is known to the State of California to cause birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.

• Always ensure proper ventilation when operating the heater.
• Installation og service skal udføres af en kvalificeret installatør, et servicebureau eller en gasleverandør.
• Opbevar eller brug ikke benzin eller andre brændbare dampe og væsker i nærheden af ​​dette eller noget andet apparat.
• Keep the area around the heater clear and free from combustible materials.

3. Produktet er slutview

The Modine HD45AS0111 is a compact, cabinet-style unit heater designed for indoor use. It features a power vent system for efficient exhaust and a grey finish for a neutral aesthetic. The unit is designed for ceiling bracket mounting.

Figure 2: Modine HD45AS0111 Garage Heater with dimensions. This image illustrates the unit's dimensions: 26 inches deep, 12 inches wide, and 16.5 inches high.

4. Opsætning og installation

Installation of this natural gas heater requires adherence to local codes and regulations. It is strongly recommended that installation be performed by a licensed professional to ensure safety and proper functionality.

4.1 Montering

• The unit is designed for ceiling bracket mounting. Ensure the mounting structure can safely support the unit's weight (approximately 60 pounds) and any associated piping.
• Position the heater to allow for adequate clearance from walls, ceilings, and combustible materials as specified in the detailed installation guide (not included in this summary).

4.2 Gas- og eltilslutninger

• Connect the natural gas supply line to the unit. All gas connections must be leak-tested by a qualified professional.
• Provide a 115 Volt electrical supply to the unit. Utilize the provided knockouts for quick access to wiring connections.
• Install a suitable thermostat (not included) in a location that accurately reflects the ambient temperature of the heated space, away from direct heat sources or drafts.

4.3 Udluftning

• The standard power exhaust system simplifies side-wall or roof venting. Use small-diameter vent pipe as specified by local codes and the full installation manual.
• Ensure all venting is properly sealed and terminates in a safe location, away from windows, doors, and air intakes.

5. Betjeningsvejledning

Once installed and all connections verified by a professional, operating your Modine Hot Dawg heater is straightforward.

1. Tænd: Ensure the electrical supply to the heater is switched on.
2. Gasforsyning: Verify that the natural gas supply valve to the heater is open.
3. Termostatindstilling: Set your thermostat to the desired temperature. The heater will automatically cycle on and off to maintain this temperature.
4. Indledende opstart: During the first few cycles, a slight odor may be present as manufacturing oils burn off. This is normal and will dissipate.
5. Nedlukning: To turn off the heater for extended periods, lower the thermostat setting to its minimum, then turn off the electrical supply and gas supply to the unit.

6. Vedligeholdelse

Regular maintenance ensures optimal performance and longevity of your heater. Always disconnect power and gas supply before performing any maintenance.

• Årlig inspektion: Have a qualified HVAC technician inspect the unit annually, preferably before the heating season. This includes checking the heat exchanger, burner, ignition system, and venting.
• Rent ydre: Keep the exterior of the unit clean and free of dust and debris.
• Klarering: Ensure that the area around the heater remains clear of obstructions to airflow and combustible materials.

7. Fejlfinding

If you encounter issues with your heater, refer to the following basic troubleshooting steps. For complex problems, contact a qualified service technician.

• Varmeapparatet starter ikke:
  • Check if the thermostat is set above the current room temperature.
  • Verify that the electrical power switch to the heater is ON.
  • Sørg for, at gasforsyningsventilen er åben.
  • Kontroller for udløste afbrydere eller sprungne sikringer.
• Utilstrækkelig varme:
  • Confirm the thermostat setting is appropriate for the desired temperature.
  • Ensure no obstructions are blocking the air intake or outlet grilles.
  • Verify the unit size is adequate for the space being heated.
• Usædvanlige lyde eller lugte:
  • If persistent or strong odors are present, immediately shut off the gas supply and contact a professional.
  • Unusual mechanical noises may indicate a fan or motor issue, requiring professional inspection.

8. Specifikationer

9. Garanti og support

For specific warranty details and to register your product, please refer to the warranty card included with your purchase or visit the official Modine website. In case of technical issues or questions not covered in this manual, please contact Modine customer support or a certified service technician.
