Timex Herre Ironman Triathlon Essential 10 40mm Ur Brugermanual

1. Introduktion

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your Timex Men's Ironman Triathlon Essential 10 40mm Watch. Please read this manual thoroughly to ensure proper use and to maximize the lifespan of your watch.

2. Produktet er slutview

The Timex Ironman Triathlon Essential 10 is a durable and lightweight digital watch designed for active lifestyles. It features a resin case, acrylic lens, and a comfortable resin strap. Key functions include a 100-hour chronograph, 10-lap memory, 24-hour countdown timer, customizable alarm, and Indiglo night-light.

2.1 Urkomponenter

• Vise: Digital screen showing time, date, and function readouts.
• MODE knap: Skifter mellem urtilstande (tid, kronograf, timer, alarm).
• INDSTIL/GENKALD-knap: Used for setting time/date and recalling lap times.
• START/SPLIT-knap: Initiates and pauses chronograph/timer, records lap splits.
• STOP/RESET-knap: Stops chronograph/timer, resets values.
• INDIGLO-knap: Aktiverer Indiglo-natlyset.

Figur 1: Forside view of the Timex Ironman Triathlon Essential 10 Watch, displaying the digital screen and button labels.

Figur 2: Side view of the watch, highlighting the MODE and SET/RECALL buttons on the left, and INDIGLO, STOP/RESET, START/SPLIT buttons on the right.

Figur 3: Tilbage view of the watch, showing the stainless steel case back with water resistance information and battery type.

3. Opsætning

3.1 Indstilling af tid og dato

1. From the Time-of-Day mode, press and hold the INDSTIL/GENKALD knappen, indtil displayet blinker.
2. Tryk på START/OPDEL button to advance the flashing segment (e.g., seconds, minutes, hours).
3. Tryk på MODE button to move to the next segment.
4. Repeat steps 2 and 3 to set the year, month, date, 12/24-hour format, and two time zones.
5. Trykke INDSTIL/GENKALD for at afslutte indstillingstilstand.

3.2 Indstilling af alarmen

1. From Time-of-Day mode, press the MODE button repeatedly until 'ALARM' appears.
2. Tryk og hold på INDSTIL/GENKALD knappen, indtil alarmtidspunktet blinker.
3. Brug START/OPDEL button to adjust the hour and minute.
4. Tryk på MODE button to toggle between AM/PM (if in 12-hour format).
5. Trykke INDSTIL/GENKALD for at gemme alarmtidspunktet.
6. For at aktivere/deaktivere alarmen skal du trykke på START/OPDEL button while in Alarm mode. An alarm icon will appear when active.

4. Betjeningsvejledning

4.1 Brug af kronografen (stopuret)

The chronograph measures elapsed time up to 100 hours with 10-lap memory.

1. From Time-of-Day mode, press the MODE button until 'CHRONO' appears.
2. Trykke START/OPDEL for at begynde timingen.
3. To record a lap time, press START/OPDEL again. The lap time will display briefly, and the chronograph will continue running in the background.
4. Trykke STOP/NULSTIL for at sætte kronografen på pause. Tryk på START/OPDEL at genoptage.
5. To reset the chronograph, press STOP/NULSTIL when paused, then press and hold STOP/NULSTIL igen.
6. For at genkalde omgangstider, tryk på INDSTIL/GENKALD mens kronografen er stoppet.

4.2 Brug af nedtællingstimeren

The 24-hour countdown timer can be used for various activities.

1. From Time-of-Day mode, press the MODE button until 'TIMER' appears.
2. Tryk og hold på INDSTIL/GENKALD button until the timer flashes.
3. Brug START/OPDEL button to adjust the hours, minutes, and seconds.
4. Tryk på MODE button to move between segments.
5. Trykke INDSTIL/GENKALD to save the timer setting.
6. Trykke START/OPDEL for at begynde nedtællingen.
7. Trykke STOP/NULSTIL for at sætte timeren på pause. Tryk på START/OPDEL at genoptage.
8. Når timeren når nul, lyder en hørbar alarm. Tryk på en vilkårlig knap for at stoppe alarmen.

4.3 Indiglo Natlampe

Tryk på INDIGLO button to illuminate the watch dial for easy viewunder dårlige lysforhold.

5. Vedligeholdelse

5.1 Vandtæthed

This watch is water resistant to 100 meters (330 feet). It is suitable for swimming and snorkeling. However, it is not recommended for diving. Do not press any buttons while the watch is submerged, as this can compromise the water resistance seal.

5.2 Udskiftning af batteri

The watch uses one Lithium Metal battery (CR2016). When the display dims or functions become erratic, it may be time to replace the battery. Battery replacement should ideally be performed by a qualified watch technician to ensure proper sealing and maintain water resistance. Opening the watch case yourself may void the warranty and compromise water resistance.

5.3 Rengøring

Rengør dit ur med en blød kludamp klud. Undgå at bruge barske kemikalier eller slibende materialer, da disse kan beskadige urkassen eller remmen.

6. Fejlfinding

7. Specifikationer

• Modelnummer: T5K608SU
• Etui materiale: Harpiks
• Linse materiale: Akryl
• Remmateriale: Harpiks
• Æske diameter: 40 mm
• Vandtæthed: 100 m (330 fod)
• Batteritype: 1 litiummetalbatteri (CR2016)
• Chronograph: 100 timer med 10-omgangs hukommelse
• Timer: 24-timers nedtælling
• Alarm: Kan tilpasses
• Yderligere funktioner: Indiglo night-light, 24-hour military time mode, 2 time zones, day/date/month calendar.
• Produktdimensioner: 10 x 7.99 x 2.99 tommer; 1.28 ounce

8. Garanti og support

This Timex watch is manufactured by Timex. For warranty information, service, or support, please refer to the warranty card included with your purchase or visit the official Timex website. You can also find more information at the Timex-butik på Amazon.
