Clatronic FFR 2916 2-i-1 Fondue Fryer Brugsanvisning

Indledning

This instruction manual provides important information regarding the safe operation, maintenance, and care of your Clatronic FFR 2916 2-in-1 Fondue Fryer. Please read these instructions thoroughly before first use and keep them for future reference. This appliance is designed for domestic use only, for preparing fried foods and fondue.

Vigtige sikkerhedsinstruktioner

Generel sikkerhed

• Always ensure the appliance is placed on a stable, heat-resistant surface, away from edges and heat sources.
• Nedsænk ikke apparatet, ledningen eller stikket i vand eller anden væske.
• Supervise children to ensure they do not play with the appliance. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Do not operate the appliance if the power cord or plug is damaged, or if the appliance malfunctions or has been damaged in any manner. Contact qualified service personnel for repair.
• Never leave the appliance unattended during operation, especially when heating oil or fat.
• Udvis ekstrem forsigtighed, når du flytter et apparat, der indeholder varm olie eller andre varme væsker.
• Do not fill the oil container above the maximum fill line or below the minimum fill line.
• Allow the appliance and oil to cool completely before cleaning or storing.

Elektrisk sikkerhed

• Sørg for, at voltage angivet på apparatet svarer til din lokale netspændingtage før tilslutning.
• Tag stikket ud af stikkontakten, når apparatet ikke er i brug, før du samler eller adskiller dele, og før du rengør det.
• Lad ikke netledningen hænge ud over kanten af ​​et bord eller bord, eller rør ved varme overflader.
• Do not use extension cords unless absolutely necessary and only if they are suitably rated for the appliance's power consumption.

Produkt overview

The Clatronic FFR 2916 is a versatile 2-in-1 appliance designed for both deep frying and fondue preparation. It features an adjustable thermostat and a control panel for ease of use.

Komponenter

• Hovedenhed med varmeelement
• Aftagelig oliebeholder
• Låg med Viewmed vindue og håndtag
• Deep Frying Basket with Removable Handle
• 6 Color-Coded Fondue Forks
• Fondue Fork Holder Ring
• Control Panel with Adjustable Thermostat and Indicator Lights
• Changeable Odour and Fumes Filter

Funktioner

• 2-in-1 functionality: Deep Fryer and Fondue Maker
• 1-liter oil capacity
• Justerbar termostat for præcis temperaturstyring
• Control panel with display for operating status
• Thermal insulated housing for safety
• Easy to clean with removable parts
• Kompakt design
• Lydløs drift

Image: The Clatronic FFR 2916 appliance shown with its deep frying basket and six color-coded fondue forks, illustrating the included accessories.

Image: Close-up of the Clatronic FFR 2916 control panel, featuring an LED display for power and heating status, and a continuously variable thermostat dial for temperature adjustment.

Opsætning

Indledende brug

1. Pak alle komponenter ud, og fjern al emballage.
2. Clean the removable oil container, lid, frying basket, and fondue forks according to the 'Cleaning and Maintenance' section.
3. Sørg for, at alle dele er helt tørre før montering og brug.

Forsamling

1. Place the main unit on a stable, heat-resistant, and level surface.
2. Insert the clean, dry oil container into the main unit.
3. For frying, place the deep frying basket into the oil container. For fondue, place the fondue fork holder ring on top of the oil container.
4. Ensure the changeable odour and fumes filter is correctly installed in the lid.

Betjeningsvejledning

Generel drift

1. Fill the oil container with cooking oil or liquid fat. Do not exceed the MAX fill line (1 liter) and ensure it is above the MIN fill line.
2. Luk låget.
3. Sæt apparatet i en passende stikkontakt. Strømindikatorlampen lyser.
4. Turn the thermostat dial to the desired temperature. The heating indicator light will illuminate, indicating the appliance is heating.
5. Once the desired temperature is reached, the heating indicator light may cycle on and off to maintain the temperature.

Stege funktion

1. After preheating the oil to the desired temperature, carefully lower the deep frying basket containing the food into the hot oil. Do not overload the basket.
2. Close the lid during frying to minimize oil splatters.
3. Fry for the recommended time or until golden brown.
4. Carefully lift the basket and allow excess oil to drain before serving.

Image: The Clatronic FFR 2916 operating as a deep fryer, with a basket of french fries immersed in hot oil, and the lid open to show the frying process.

Fondue Function

1. Ensure the fondue fork holder ring is correctly placed on the oil container.
2. Preheat the oil or fondue liquid (e.g., cheese, chocolate) to the desired temperature using the thermostat.
3. Use the color-coded fondue forks to dip food items into the hot liquid.
4. Place used forks in the designated slots on the holder ring to prevent dripping and keep them organized.

Image: A collage demonstrating various fondue types: cheese fondue with bread, classic meat fondue, and chocolate fondue with fruits, highlighting the versatility of the appliance.

Image: The Clatronic FFR 2916 configured for fondue, with the fondue fork holder ring in place and various raw meat cubes arranged on serving plates around the unit.

Rengøring og vedligeholdelse

Regular cleaning ensures optimal performance and extends the lifespan of your appliance. Always unplug the appliance and allow it to cool completely before cleaning.

Generel rengøring

1. Remove the oil container, frying basket, lid, and fondue forks.
2. Wash these removable parts in warm, soapy water. Rinse thoroughly and dry completely. Some parts may be dishwasher safe; refer to specific product markings.
3. Tør ydersiden af ​​hovedenheden af ​​med enamp klæde. Brug ikke slibende rengøringsmidler eller skuremidler.
4. Nedsænk aldrig hovedenheden i vand.

Udskiftning af filter

The appliance is equipped with a changeable odour and fumes filter in the lid. Replace the filter periodically to maintain effective odour reduction.

1. Open the lid and locate the filter compartment.
2. Fjern det gamle filter, og bortskaf det ansvarligt.
3. Insert a new, compatible filter into the compartment, ensuring it is seated correctly.
4. Luk filterrummet forsvarligt.

Image: A diagram illustrating the process of changing the odour and fumes filter, showing the filter being removed and inserted into the lid compartment.

Fejlfinding

Specifikationer

• Mærke: Clatronic
• Modelnummer: FFR2916
• Farve: Hvidgrå
• Produktdimensioner: 19 x 19 x 24 cm
• Varens vægt: 900 g
• Kapacitet: 1 Litre (Oil/Fat)
• Strøm / Wattage: 900 watt
• Voltage: 230 V
• Materiale: Plast
• Særlige funktioner: Thermal Insulated
• Automatisk sluk: Ingen

Garanti og support

For warranty information, please refer to the warranty card included with your purchase or contact your retailer. For technical support or service, please contact Clatronic customer service or an authorized service center. Keep your proof of purchase for any warranty claims.
