ROJECO 2-in-1 Dog Training and Bark Collar User Manual

Indledning

Thank you for choosing the ROJECO 2-in-1 Dog Training and Bark Collar. This device is designed to assist in effective dog training through remote control and automatic bark correction. Please read this manual thoroughly before use to ensure proper operation and the safety of your pet.

Vigtige sikkerhedsoplysninger

• This product is intended for dogs only. Not for use on humans or other animals.
• Lad ikke halsbåndet sidde på din hund i mere end 12 timer om dagen.
• Regularly check your dog's neck for signs of irritation or sores. If found, discontinue use until the skin heals.
• The static correction mode should be used responsibly and only after other modes (beep, vibration) have been attempted.
• Opbevares utilgængeligt for børn.
• Ensure the contact points are properly positioned on your dog's skin for effective operation.
• Denne enhed er ikke et legetøj.

Pakkens indhold

The ROJECO 2-in-1 Dog Training and Bark Collar package includes the following items:

• 1x fjernbetjeningssender
• 1x Training Collar Receiver
• 1x Justerbar nylonhalsbånd
• 1x USB opladningskabel
• 2 sæt kontaktpunkter (korte og lange)
• 2x Silicone Conductive Caps
• 1x Test Light Tool
• 1x Lanyard for Remote
• 1x brugermanual

Image: All components included in the ROJECO 2-in-1 Dog Training and Bark Collar package.

Opsætningsvejledning

1. Opladning af enhederne

Before first use, fully charge both the remote control transmitter and the collar receiver. A full charge typically takes 2 hours.

• Tilslut USB-opladerkablet til opladningsportene på både fjernbetjeningen og modtageren.
• Sæt den anden ende af USB-kablet i en strømadapter, computer, bærbar computer eller powerbank.
• The battery indicator on the devices will show charging status and turn solid when fully charged.

Image: The remote control and collar receiver connected to the USB charging cable for charging. Both devices are shown with battery indicators.

Expected Battery Life: Transmitter: up to 180 days. Receiver: 20-40 days.

2. Attaching Contact Points and Collar Strap

Select the appropriate contact points based on your dog's coat length. Use shorter points for dogs with fine coats and longer points for dogs with thick coats. For dogs with very short coats or if static correction is not desired, the needle-free design allows for use without contact prongs.

• Skru de valgte kontaktpunkter fast på modtageren.
• If using static correction, ensure the contact points make direct contact with your dog's skin.
• Thread the adjustable nylon strap through the receiver.

Image: The collar receiver showing options for long contact needles for thick coats, short needles for fine coats, and a removable needle-free design.

3. Montering af kraven

Proper fit is crucial for comfort and effectiveness. The collar is adjustable from 0-26 inches to fit dogs of all sizes.

• Place the receiver on your dog's neck, ensuring the contact points are centered beneath the neck.
• Juster remmen, så den sidder stramt, men ikke for stramt. Du skal kunne få to fingre komfortabelt mellem remmen og din hunds hals.
• Trim any excess strap length if necessary, and use a lighter to seal the cut edge to prevent fraying.

Image: Three dogs of different breeds and sizes wearing the ROJECO training collar, demonstrating its adjustable fit for 0-26 inch collars.

Driftstilstande

The ROJECO 2-in-1 collar offers both remote training and automatic anti-barking functions.

1. Remote Training Mode

Use the remote control for targeted obedience training. The remote has a range of up to 3300 feet.

• Beep Mode (1-5 levels): Leverer en hørbar tone.
• Vibration Mode (1-16 levels): Delivers a tactile vibration.
• Safe Shock Mode (0-99 levels): Delivers a static correction. Level 0 disables static correction.

To adjust levels: Click the top button to select the function (Beep, Vibration, or Shock). Adjust the level using the rotary button. Press the corresponding function keypad to activate.

Image: Diagram illustrating how to select a function and adjust its level on the remote control using the top button and rotary dial.

The remote control can pair with up to three collars, allowing you to train multiple dogs individually by switching between dog channels (Dog 1, Dog 2, Dog 3).

Image: A person holding the remote control, demonstrating its use during manual training with a dog.

Billede: En luftfoto view illustrating the 3300-foot remote control range, showing dogs at various distances from the remote.

2. Automatic Anti-Barking Mode

The collar features a built-in AI smart chip that accurately identifies dog barks and filters out ambient noise, preventing false triggers. It offers 5 adjustable sensitivity levels and 3 combined working modes.

• Arbejdstilstande: Vibration, Beep + Vibration, Beep + Vibration + Safe Shock.
• Progressive Correction: The collar delivers progressively stronger corrections (starting with gentle vibration) if barking continues.
• Sikkerhedspause: After 5 consecutive triggers, the collar automatically enters a 30-second safety pause to prevent over-correction. It resets to the previous level after 30 seconds of silence.

Image: A dog wearing the collar, with an illustration showing the automatic bark control feature activating in response to barking.

Image: An illustration of the collar's smart AI chip, highlighting its ability to filter out ambient noise like TV sound, chat, vacuum cleaner noise, and other dogs barking, to prevent false triggers.

Image: Visual representation of the 5 automatic barking prevention modes, showing progressive levels of correction from gentle vibration to beep + vibration + 90% static.

Yderligere funktioner

• IPX7 Vandtæt: The receiver is IPX7 waterproof, allowing your dog to play in rain, wet grass, or shallow water. The remote control is not waterproof and should not be submerged.
• LED lys: The remote control includes a built-in LED light to help locate your dog quickly at night or in low-light conditions.
• Reflective Collar: The collar strap features reflective elements for enhanced visibility during nighttime walks.

Image: A dog splashing in water, demonstrating the IPX7 waterproof capability of the collar receiver. Smaller images show the collar in rain and during bathing.

Image: A person using a flashlight while walking a dog at night, showcasing the remote's flashlight feature and the collar's reflective design for safety.

Opretholdelse

• Rensning: Tør halsbåndet og fjernbetjeningen af ​​med en reklameamp cloth. Do not submerge the remote in water.
• Collar Removal: Remove the collar before bathing your pet to prevent skin irritation and ensure proper drying.
• Regelmæssig inspektion: Periodically check the collar for wear and tear, especially the contact points and strap.

Fejlfinding

Specifikationer

• Produktdimensioner: 9.84 x 1.5 x 0.1 inches (Collar); 10.88 ounces (Item Weight)
• Modelnummer: PD 511
• Batterier: 2 ikke-standardbatterier kræves (inkluderet)
• Fjernbetjeningens rækkevidde: Op til 3300 fod
• Vandtæt vurdering: IPX7 (Receiver only)
• Opladningstid: Cirka 2 timer
• Materiale: Nylon (Collar strap)
• Farve: Grøn
• Raceanbefaling: All Dog Breeds (Small, Medium, Large)

Garanti og support

This ROJECO product comes with a 1 års fabriksgaranti.

For technical support, warranty claims, or further assistance, please contact ROJECO customer service through the retailer's platform or visit the official ROJECO webwebsted. Gem venligst din købsbevis for at validere garantien.

Manufacturer: Shenzhen PaiPai Technology Co., Ltd.
