VEVOR Automatic Smart Curtain Opener (Model LY-1998) User Manual

1. Introduktion

Thank you for choosing the VEVOR Automatic Smart Curtain Opener. This device is designed to automate your existing curtains, offering convenience through app, remote, and voice control. It supports various curtain track types including Roman rods, U-shaped, and I-shaped rails. This manual provides essential information for safe and efficient use of your new curtain opener.

2. Sikkerhedsinstruktioner

• Læs alle instruktioner omhyggeligt før installation og drift.
• Hold enheden væk fra vand og miljøer med høj luftfugtighed.
• Forsøg ikke selv at adskille eller reparere enheden. Kontakt kundesupport for at få hjælp.
• Ensure the curtain rod or track is securely installed and can support the weight of the curtains and the opener (Max Load: 35 lbs / 16 kg).
• Keep children and pets away from the moving curtains during operation.
• Use only the provided accessories and power cables.
• Before initial use, check the opening/closing direction and calibrate the travel.

3. Pakkens indhold

Bekræft at alle varer er til stede i din pakke:

• 2 x Main Unit
• 1 x fjernbetjening
• 1 x Wireless Gateway
• 2 x Type-C kabel
• 4 x Roman Rod Hooks
• 2 x 3m Traction Rope
• 2 x Connector Plate
• 1 x Brugermanual (dette dokument)

4. Produktet er slutview

The VEVOR Automatic Smart Curtain Opener is designed for easy integration with various curtain systems. Its compact design ensures it remains discreetly behind your curtains.

Kompatibilitet

This device is compatible with:

• Roman Rods: Suitable for diameters of 0.3 - 1.6 inches (8 - 40 mm).
• U-Shaped Rails
• I-Shaped Rails

5. Opsætning og installation

The VEVOR Automatic Smart Curtain Opener is designed for easy, tool-free installation on your existing curtain setup.

Installationstrin:

1. Attach Main Units: Hang the main units onto your curtain rod or track. For Roman rods, use the provided Roman Rod Hooks. For U-shaped and I-shaped rails, use the quick-swap adapters. Ensure the units are securely attached and can move freely.
2. Connect Traction Rope (if applicable): For certain curtain types, you may need to use the traction rope to ensure smooth movement.
3. Opladningsenheder: Fully charge both main units using the provided Type-C cables before initial use.
4. Download app: Download the companion app (e.g., Tuya Smart or Smart Life, refer to the quick start guide for specific app name) on your smartphone.
5. Pair the Hub (Wireless Gateway):
   • Keep your phone connected to the internet.
   • Press the power button on the main unit twice; the blue light will flash.
   • Power on the wireless gateway and long-press its button for 5 seconds until the red light stays on.
   • The gateway will beep once paired.
6. Tilføj enhed i appen:
   • Åbn appen, og tryk på "Tilføj enhed".
   • Select "WiFi smart curtain robot" or similar option.
   • Follow the in-app instructions to complete the device addition and name your curtain opener.
7. Calibrate Travel: Once connected, use the app or remote to calibrate the full open and closed positions of your curtains. This ensures the opener knows the exact travel distance for your specific setup.

6. Betjeningsvejledning

Your VEVOR Automatic Smart Curtain Opener offers multiple control methods for maximum convenience.

6.1. Fjernbetjening

Use the included remote control to open, close, or stop your curtains from a distance of up to 32.8 ft (10 m).

6.2. Appkontrol

Manage your curtains anytime, anywhere using the dedicated smartphone app. The app provides full control over opening/closing, setting schedules, and accessing smart features.

6.3. Stemmekontrol

The device is compatible with Amazon Alexa and Google Assistant. Once integrated, you can use voice commands to control your curtains, such as "Hey Alexa, close the curtains at 9:00 pm."

7. Smarte funktioner

Enhance your daily routine with the intelligent features of your curtain opener:

• Adjustable Range & Position Control: Precisely set the opening and closing limits to match your window dimensions.
• Timere og tidsplaner: Program specific times for your curtains to open and close automatically, aligning with your daily schedule or sunrise/sunset.
• Light and Temperature Sensing: The device can be configured to react to ambient light and temperature changes, automatically adjusting curtains for optimal comfort and energy efficiency.
• Brugerdefinerede scener: Create personalized scenes within the app to control multiple smart devices, including your curtains, with a single command.
• Stille tilstand: Ensures silent operation, ideal for bedrooms and nurseries, preventing disturbance during sleep.

8. Batterilevetid og opladning

Each main unit is equipped with two built-in 2000mAh batteries, providing up to six months of runtime on a full charge with regular use. Recharge using the provided Type-C cables.

9. Vedligeholdelse

• Rensning: Tør enheden af ​​med en blød, tør klud. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• Batteripleje: Recharge the batteries when the low battery indicator appears. Avoid fully draining the batteries frequently to prolong their lifespan.
• Sporinspektion: Periodically check your curtain rod or track for any obstructions or damage that might hinder the smooth operation of the opener.
• Firmwareopdateringer: Check the app regularly for any available firmware updates to ensure optimal performance and access to new features.

10. Fejlfinding

If you encounter issues with your VEVOR Automatic Smart Curtain Opener, refer to the following common solutions:

For further assistance, please refer to the in-app help section or contact VEVOR customer support.

11. Specifikationer

12. Garanti og support

VEVOR products come with a standard warranty. For specific warranty details, product registration, or technical support, please visit the official VEVOR webwebstedet eller kontakt deres kundeservice direkte. Gem din købskvittering til garantikrav.
