Brugermanual til elektrisk sækkevogn til trappeophæng

1. Introduktion

This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Electric Sack Truck Stair Climber. Designed to assist with moving heavy goods up and down stairs, this device significantly reduces manual effort and improves efficiency. Please read this manual thoroughly before initial use to ensure proper handling and to maximize the product's lifespan.

Figur 1: Forside og side view of the Electric Sack Truck Stair Climber.

2. Sikkerhedsoplysninger

Always prioritize safety when operating the Electric Sack Truck Stair Climber. Failure to follow safety guidelines can result in injury or damage to the equipment.

• Inspektion: Before each use, inspect the product for any signs of damage or wear. Ensure all components are securely in place.
• Belastningskapacitet: Do not exceed the maximum load capacity of 400 kg. Overloading can lead to instability and damage.
• Stabilitet: Always ensure the load is balanced and securely fastened to the loading plate before attempting to move it.
• Trappenavigation: Exercise extreme caution when ascending or descending stairs. Maintain a firm grip on the handle and control the speed.
• Batterisikkerhed: Use only the provided charger and battery. Do not expose the battery to extreme temperatures or moisture.
• Opbevaring: Store the product in a good, dry condition when not in use.

Figure 2: Important safety warnings regarding product handling and condition.

3. Produktkomponenter og funktioner

Familiarize yourself with the key components of your Electric Sack Truck Stair Climber:

Figure 3: Labeled components of the Electric Sack Truck Stair Climber.

• Kontrolkontakt: Activates and controls the motor for stair climbing.
• Batteridisplay: Indicates the current battery charge level.
• Fixed Handle & Retractable Handle: Provides grip and allows for height adjustment (110cm-160cm) for ergonomic operation.
• Removable Lithium Battery: Powers the motor, designed for quick access and easy removal for charging.
• Børsteløs motor: A 1200W pure copper motor providing powerful, durable, and stable performance with a low failure rate.
• S-Shaped Arm (Double-layer support arm): Made of reinforced alloy steel, providing high hardness and uniform force distribution for enhanced load-bearing capacity.
• Pneumatic Rubber Tires: Durable wheels designed for stability and smooth movement.
• Loading Plate: Features a slope design at the front end for smoother loading and unloading of cargo.
• Hjulnav: Constructed from high-strength steel for long service life and large load capacity.
• Tire Tripod Bracket: Laser-cut one-piece bracket, designed for durability and resistance to deformation under heavy loads.

Figure 4: Detail of the robust tire tripod bracket and double-layer S swing arm.

Figure 5: Detail of the loading plate and wheel hub for efficient cargo handling.

Figure 6: Benefits of the high-quality pure copper brushless motor.

4. Opsætning

Your Electric Sack Truck Stair Climber comes with the following components:

• 1 x Electric Stairlift Unit
• 1 x batteri
• 1 x oplader
• 1 x Brugermanual (dette dokument)

4.1 Batteriinstallation og opladning

1. Locate the battery compartment on the main unit. The design allows for portable quick access.
2. Insert the removable lithium battery into the compartment, ensuring it clicks securely into place.
3. Before first use, fully charge the battery using the provided charger. Connect the charger to the battery port and then to a standard power outlet.
4. The battery display will indicate charging status. A full charge can support climbing approximately 6000 steps.
5. Afbryd opladeren, når batteriet er fuldt opladet.

5. Betjeningsvejledning

5.1 Forberedelse til drift

1. Sørg for, at batteriet er tilstrækkeligt opladet.
2. Adjust the retractable handle to a comfortable height (between 110cm and 160cm) to maintain an upright posture and reduce strain.
3. Place the item to be transported onto the loading plate. Ensure the load is centered and stable. For irregular items, consider using straps (not included) to secure them.

5.2 Ascending Stairs

1. Position the stair climber at the base of the stairs with the loading plate facing the first step.
2. Activate the control switch to engage the motor.
3. Gently guide the unit upwards, allowing the climbing mechanism to lift the load onto each step. Maintain a steady pace and firm control.

5.3 Descending Stairs

1. Position the stair climber at the top of the stairs, with the loading plate facing downwards.
2. Activate the control switch.
3. Carefully guide the unit downwards, allowing the climbing mechanism to descend each step. Control the descent speed to prevent sudden movements.

5.4 General Movement

For flat surfaces, the unit can be tilted back and rolled on its pneumatic rubber tires like a standard hand truck.

Figur 7: Eksamples of how the Electric Sack Truck Stair Climber simplifies heavy object handling.

6. Vedligeholdelse

Regular maintenance ensures the longevity and optimal performance of your stair climber.

• Rensning: Tør enheden af ​​med adamp cloth after use to remove dirt and debris. Avoid using harsh chemicals or abrasive cleaners.
• Batteripleje:
  • Always fully charge the battery before storing the unit for extended periods.
  • Recharge the battery periodically (e.g., every 3 months) even if not in use, to maintain battery health.
  • Do not allow the battery to completely discharge for prolonged periods.
• Motor: The brushless motor is designed to be maintenance-free, offering long life and low failure rates. No user-serviceable parts.
• Wheels and Moving Parts: Periodically check wheels and moving parts for any obstructions or signs of wear. Ensure all bolts and fasteners are tight.
• Opbevaring: Store the stair climber in a dry, cool place, away from direct sunlight and extreme temperatures.

7. Fejlfinding

If you encounter issues with your Electric Sack Truck Stair Climber, refer to the following common problems and solutions:

Hvis problemet fortsætter efter at have forsøgt disse løsninger, bedes du kontakte kundesupport.

8. Specifikationer

Figure 8: Approximate dimensions of the Electric Sack Truck Stair Climber.

9. Garanti og support

Your satisfaction is important to us. If you are not satisfied with our product or encounter any issues not covered in this manual, please contact our customer service immediately.

We are committed to providing the best solution within 24 hours. Please refer to your purchase documentation for specific warranty terms and contact information for the seller.
