FOHERE Countertop Ice Maker Machine User Manual

1. Introduktion

Thank you for choosing the FOHERE Countertop Ice Maker Machine. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new ice maker. Please read it thoroughly before first use and keep it for future reference.

This portable ice maker is designed to produce bullet-shaped ice cubes quickly and conveniently, perfect for home, kitchen, or office use. It features a self-cleaning function and offers two ice cube sizes to suit your needs.

2. Sikkerhedsinstruktioner

WARNING: To reduce the risk of fire, explosion, electric shock, or injury when using your ice maker, follow these basic safety precautions:

• Please keep this machine upright for 24 hours before the first use. Do not tilt the machine.
• Place the ice maker on a dry, ventilated countertop away from any heat source.
• Do not exceed the MAX water line when adding water to the water tank.
• Only fill the tank with edible water. Other liquids such as coffee or drinks are not allowed. Ensure water added does not contain impurities.
• Do not touch the evaporator while the unit is making ice, as it may burn your skin.
• Always keep the lid closed unless filling water or removing ice.
• Brug ikke mekaniske anordninger til at afrime køleskabet. Punkter ikke kølemiddelslanger.
• This product uses flammable refrigerant. Service should only be performed by trained service personnel.
• Hold ventilationsåbningerne i apparatets kabinet eller i den indbyggede struktur fri for forhindringer.

3. Produktet er slutview

The FOHERE Countertop Ice Maker is designed for efficiency and ease of use. Below are its main components and features:

• Kontrolpanel: Intuitive buttons for power, ice size selection, and self-cleaning.
• Iskurv: Aftagelig kurv til opsamling af isterninger.
• Ice Scoop: Inkluderet for nem isudtagning.
• Vandtank: Internal reservoir for water supply.
• Evaporator Rods: Stainless steel rods where ice cubes are formed.
• Infrarød sensor: Automatically detects when the ice basket is full or water needs refilling.
• Selvrensende funktion: Automated cleaning cycle to prevent limescale and odors.
• Two Ice Sizes: Small (0.8" x 1") for smoothies and large (1.3" x 1") for drinks/chilling.
• Stille drift: Fungerer ved under 40 dB.

Figure 3.1: FOHERE Countertop Ice Maker Machine with included accessories.

Figure 3.2: Internal construction showing the food-grade PP material, high-density foaming layer, and premium stainless steel exterior.

4. Opsætning

1. Pak ismaskinen ud: Carefully remove the ice maker and all accessories (ice basket, ice scoop, user manual) from the packaging. Ensure all packing materials and tape are removed from the unit, especially from inside the ice-making area.
2. Placering: Place the ice maker on a stable, level, and dry countertop. Ensure it is away from direct sunlight or any heat-producing appliances. Allow adequate ventilation around the unit.
3. Indledende standby: For optimal performance, allow the ice maker to stand upright for at least 24 hours before plugging it in and using it for the first time. This allows the refrigerant to settle.
4. Tilsæt vand: Open the lid and remove the ice basket. Fill the water tank with clean, potable water up to the "MAX" water line indicated inside the reservoir. Do not overfill.
5. Replace Basket: Place the ice basket back into its position and close the lid.

Figure 4.1: Filling the water tank up to the MAX line.

5. Betjeningsvejledning

1. Tænd: Plug the ice maker into a grounded electrical outlet. Press the "POWER" button on the control panel to turn on the unit. The power indicator light will illuminate.
2. Vælg isstørrelse: The default ice size is usually large. To switch between small and large ice cubes, press the "SELECT" button. The corresponding indicator light will show your selection. Small ice cubes are ideal for smoothies, while large cubes are better for chilling drinks.
3. Isproduktion: The ice maker will begin the ice-making cycle automatically. The first batch of 9 bullet ice cubes typically takes 6-8 minutes. Subsequent batches may be faster. Note that the first 5-10 batches might not be as fast or perfect as the machine stabilizes.
4. Isfuld advarsel: When the ice basket is full, the "ICE FULL" indicator light will brighten, and the machine will pause operation. Remove ice cubes from the basket and use them or transfer them to a freezer for storage. The machine will resume ice making once space is cleared.
5. Add Water Alert: If the water level in the tank is too low, the "ADD WATER" indicator light will illuminate, and the machine will stop. Refill the water tank as per step 4 in the Setup section.

Figure 5.1: The ice maker produces a batch of ice in approximately 6 minutes.

Figure 5.2: Choose between two ice sizes for different beverage and chilling needs.

Figure 5.3: The 'Add Water' indicator alerts you when the water tank needs refilling.

Figure 5.4: The 'Ice Full' indicator signals that the ice basket is at capacity.

6. Vedligeholdelse & Rengøring

Regular cleaning and maintenance will ensure the longevity and hygiene of your FOHERE ice maker.

6.1 Selvrensende funktion

1. Initiate Self-Clean: With the unit plugged in and water in the tank, press the "SELECT" button until the cleaning light (brush icon) illuminates. After about 5 seconds, the self-cleaning cycle will begin.
2. Cyklus afslutning: The self-cleaning process will run for approximately 30 minutes. Once complete, the unit will return to standby mode.

Figure 6.1: The self-cleaning function helps maintain hygiene and prevent mineral buildup.

6.2 Manual Cleaning & Draining

1. Afløbsvand: After the self-cleaning cycle or when storing the unit, drain any remaining water. Locate the rubber plug at the bottom of the unit. Place a cup or container underneath and pull out the plug to drain the water.
2. Tør indvendigt af: Use a soft cloth to wipe down the interior of the water tank and ice basket. For deeper cleaning, you can use a solution of water and a small amount of baking soda (approx. 1/2 teaspoon per 2 cups of water) or vinegar.
3. Tør grundigt: Ensure all internal components are thoroughly dry before storing. If storing for a long period, leave the lid open to allow air circulation and prevent mold growth.

7. Fejlfinding

8. Specifikationer

• Mærke: FOHERE
• Modelnavn: Countertop Ice Maker Machine (ICM1250)
• Produktdimensioner: 11.4" D x 8.7" B x 11.8" H
• Vægt: Cirka 18.6 pund
• Kapacitet: 2 liter (vandtank)
• Isproduktion: Op til 18 kg i døgnet
• Ice Cube Shape: Kugle
• Isterningstørrelser: Small (0.8" x 1"), Large (1.3" x 1")
• First Batch Time: 6-8 minutter
• Wattage: 120 watt
• Oprindelsesland: Kina

Figure 8.1: Compact dimensions for easy placement on countertops.

9. Garanti og support

FOHERE is dedicated to providing high-quality products and outstanding customer support.

• Garanti: This ice maker is backed by a 24-month warranty from the original purchase date.
• Teknisk support: Lifetime technical support is available for any queries or issues you may encounter with your ice cube maker.
• Kontakte: For any questions or support needs, please feel free to reach out to us anytime. Refer to the contact information provided in your original purchase documentation or on the FOHERE official webwebsted.
