TEXUM Portable Car Washer Wireless 48V High Pressure Cleaner Machine TX/BPW1 User Manual

1. Introduktion

Thank you for choosing the TEXUM Portable Car Washer Wireless 48V High Pressure Cleaner Machine. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your device. Please read it thoroughly before first use and retain it for future reference.

Sikkerhedsoplysninger

• Always wear appropriate personal protective equipment, such as safety glasses, during operation.
• Ret ikke sprøjtepistolen mod mennesker, dyr eller elektrisk udstyr.
• Ensure all connections are secure before operating the machine.
• Hold børn og kæledyr væk fra operationsområdet.
• Do not operate the machine if any parts are damaged.
• Use only clean water for operation.

2. Pakkens indhold

Pak forsigtigt alle varer ud, og sørg for, at du har modtaget alle komponenterne anført nedenfor. Hvis der mangler eller er beskadigede dele, bedes du kontakte kundesupport.

Figur 2.1: Alle komponenter er inkluderet i pakken.

• Pressure Gun with Extension Rod
• 48V batteripakke
• Battery Charger (Adapter)
• Inlet Hose Pipe (3 meters)
• Vandfilter
• Quick Connector
• Brass Quick Connector
• 0° Nozzle Tip
• 45° Nozzle Tip
• Foam Dispenser (Soap Bottle)
• Microfiber Sponge

3. Produktet er slutview

Familiarize yourself with the main parts of your TEXUM Portable Car Washer.

Figur 3.1: TEXUM Portable Car Washer and its accessories.

Nøglefunktioner:

• Trådløs drift: Powered by a 48V battery for portability.
• Højtryksudgang: Delivers up to 40 Bar pressure for effective cleaning.
• Alsidig vandkilde: Can draw water from buckets, bottles, or taps.
• Flere dyser: Includes 0° and 45° nozzles for various cleaning tasks, plus a foam dispenser.
• Letvægtsdesign: Easy to handle and transport for various applications.

4. Opsætningsvejledning

4.1. Opladning af batteriet

1. Connect the charger adapter to the battery pack.
2. Sæt opladeren i en almindelig stikkontakt.
3. Allow the battery to charge fully before first use. The indicator light on the charger will typically change color when charging is complete.

4.2. Assembling the Washer

1. Fastgør forlængerstangen: Securely twist the extension rod onto the pressure gun.
2. Attach Nozzle/Foam Dispenser: Select the desired nozzle (0° or 45°) or the foam dispenser and attach it to the end of the extension rod. Ensure it clicks into place or is tightly screwed.
3. Indsæt batteri: Slide the charged battery pack into the base of the pressure gun until it locks securely.

4.3. Connecting the Water Source

The TEXUM Portable Car Washer can draw water from various sources.

Figur 4.1: Water filter and compatible water sources.

1. Vedhæft filter: Connect the water filter to one end of the inlet hose pipe.
2. Connect Hose to Washer: Attach the quick connector to the other end of the inlet hose pipe, then connect it to the water inlet on the pressure gun.
3. Dykfilter: Place the filter end of the hose into your chosen water source (bucket, pool, etc.). Ensure the filter is fully submerged to prevent air intake.
4. Priming (Important for first use or after hose is empty):
   • Completely submerge the inlet hose in water to remove any trapped air.
   • Alternatively, place the water source (e.g., bucket) higher than the pressure washer and run the unit until water reaches the wand. Once the hose is full of water, the pressure washer will operate correctly.

5. Betjeningsvejledning

5.1. Start af vaskemaskinen

1. Ensure the battery is charged and installed, and the water hose is connected and primed.
2. Point the nozzle away from yourself and others.
3. Press the trigger on the pressure gun to start the water flow.

5.2. Brug af forskellige dyser

The washer comes with different nozzles for various cleaning applications.

Figur 5.1: Multifunctional nozzle applications.

• 0° Nozzle (Red): Provides a concentrated, high-pressure stream for tough stains and targeted cleaning. Use with caution on delicate surfaces.
• 45° dyse (hvid): Delivers a wider fan spray, ideal for general washing, rinsing, and covering larger areas like car surfaces.
• Foam Dispenser: Fill the dispenser with car wash soap or cleaning solution. Attach it to the gun for foam application, which helps loosen dirt before rinsing.

5.3. Generelle rengøringstips

• Test altid sprayen på et ikke-synligt område først for at undgå skader.
• Maintain a safe distance from the surface being cleaned, especially with the 0° nozzle.
• Work from top to bottom when cleaning vehicles or vertical surfaces to allow gravity to assist in rinsing away dirt.
• For stubborn dirt, apply foam, let it dwell for a few minutes, then rinse with a 45° nozzle.

Figur 5.2: Multi-purpose applications of the TEXUM Portable Car Washer.

6. Vedligeholdelse

6.1. Efter hver brug

• Skyl grundigt: Run clean water through the washer for a few minutes to flush out any detergent or debris.
• Afbryd vand: Turn off the water source and disconnect the inlet hose.
• Lindre trykket: Tryk på aftrækkeren for at udløse eventuelt resterende tryk i systemet.
• Rengøring af dyser: Remove nozzles and clean any blockages with a small pin or needle.
• Rens filter: Remove and rinse the water filter to prevent clogging.
• Tør ned: Tør enhedens ydre af med adamp klæde.

6.2. Opbevaring

• Remove the battery pack and store it separately in a cool, dry place.
• Drain all water from the pump, hose, and accessories to prevent freezing damage in cold climates.
• Store the washer and its accessories in a clean, dry, and protected area, away from direct sunlight and extreme temperatures.

7. Fejlfinding

8. Specifikationer

9. Garanti og support

TEXUM products are manufactured to high-quality standards. For specific warranty details, please refer to the warranty card included with your purchase or visit the official TEXUM website. If you encounter any issues or require technical assistance, please contact TEXUM customer support.

Fabrikant: Texum Buildtech Private Limited

Oprindelsesland: Indien
