Indledning
Thank you for choosing the UrbanX FM0190 Waterproof Bluetooth Speaker. This speaker is designed to provide powerful stereo sound in a portable, durable, and waterproof package. Featuring Bluetooth V5.2 connectivity and True Wireless Stereo (TWS) pairing, it is suitable for various environments, from outdoor adventures to home use. Please read this manual carefully to ensure proper use and maintenance of your device.
Nøglefunktioner omfatter:
- Kraftig stereolyd: Equipped with a full-frequency unit and BASSBOOST technology for clear audio.
- IPX7 vandtæt bedømmelse: Designed to withstand submersion in water, making it ideal for beach or poolside use.
- True Wireless Stereo (TWS) Parring: Connect two UrbanX speakers for an immersive surround sound experience.
- Bærbart design: Kompakt og let med en fast løkke for nem transport.
- Lang batterilevetid: Op til 20 timers uafbrudt afspilning på en enkelt opladning.
- Alsidige afspilningsmuligheder: Supports Bluetooth, SD/TF card, and AUX input.
Produkt overview
The UrbanX FM0190 speaker features a robust and compact design. Familiarize yourself with the speaker's components for optimal use.
Image: The UrbanX FM0190 speaker, highlighting its powerful audio capabilities with a detailed view of its 1.69-inch driver and BASSBOOST technology.
Højttalerkomponenter
- Power knap: Bruges til at tænde eller slukke for højttaleren.
- Lydstyrkeknapper (+/-): Justerer afspilningslydstyrken.
- Multifunktionsknap (O): Controls playback (play/pause), call management, and TWS pairing.
- Type-C opladningsport: Til opladning af højttalerens interne batteri.
- SD/TF-kortplads: Til afspilning af musik direkte fra et hukommelseskort.
- AUX-indgangsport: Til tilslutning af eksterne lydenheder via et 3.5 mm lydkabel.
- Indbygget mikrofon: Til håndfri opkald.
- Carrying Loop: For nem transport.
Opsætning
1. Opladning af højttaleren
Before first use, fully charge the speaker. Connect the provided Type-C charging cable to the speaker's charging port and a compatible USB power adapter (not included). The charging indicator light will illuminate during charging and turn off once fully charged. A full charge typically takes 3-4 hours.
2. Tænd/sluk
- For at tænde: Press and hold the Power button for approximately 2-3 seconds until you hear an audible prompt and the indicator light flashes.
- For at slukke: Tryk på tænd/sluk-knappen og hold den nede i cirka 2-3 sekunder, indtil du hører en lydmeddelelse, og indikatorlampen slukker.
3. Bluetooth-parring
After powering on, the speaker will automatically enter Bluetooth pairing mode, indicated by a flashing blue light. Follow these steps to connect your device:
- Sørg for, at Bluetooth er aktiveret på din smartphone, tablet eller anden lydenhed.
- Søg efter Bluetooth devices and select "UrbanX FM0190" from the list.
- Når der er oprettet forbindelse, hører du en bekræftelseslyd, og indikatorlampen lyser konstant blåt.
Højttaleren vil automatisk forsøge at genoprette forbindelsen til den sidst parrede enhed, når den tændes.
4. Ægte trådløs stereo (TWS) parring
For an enhanced stereo experience, you can pair two UrbanX FM0190 speakers together.
Image: Two UrbanX FM0190 speakers shown wirelessly connected to a tablet, illustrating the True Wireless Stereo (TWS) pairing feature for a surround sound experience.
- Ensure both UrbanX FM0190 speakers are powered on and not connected to any other Bluetooth device.
- On one of the speakers (this will be the primary speaker), double-press the Multi-function button (O). The speaker will enter TWS pairing mode.
- The two speakers will automatically search for and connect to each other. You will hear a confirmation sound once TWS pairing is successful.
- Once TWS paired, connect your audio device to the primary speaker via Bluetooth as described in step 3. Both speakers will now play audio in stereo.
Betjening af højttaleren
1. Basic Music Playback
- Afspil/pause: Press the Multi-function button (O) once.
- Lydstyrke op: Tryk på '+'-knappen.
- Skrue ned for lyden: Tryk på '-' knappen.
- Næste nummer: Tryk på '+'-knappen og hold den nede.
- Forrige nummer: Tryk på '-'-knappen og hold den nede.
2. Håndfri opkald
With the built-in microphone, you can answer calls directly through the speaker when connected to your smartphone.
- Besvar opkald: Press the Multi-function button (O) once when a call comes in.
- Afslut opkald: Press the Multi-function button (O) once during a call.
- Afvis opkald: Press and hold the Multi-function button (O) for 2 seconds when a call comes in.
3. SD/TF Card Playback
Insert a formatted SD/TF card (up to 32GB) with music files into the designated slot. The speaker will automatically switch to SD/TF card mode and begin playing music. Use the basic music playback controls.
4. AUX-indgangstilstand
Connect an external audio device (e.g., MP3 player) to the speaker's AUX input port using a 3.5mm audio cable. The speaker will automatically switch to AUX mode. Volume can be controlled via the speaker or the connected device.
Opretholdelse
Proper care ensures the longevity and performance of your UrbanX FM0190 speaker.
1. Rensning
- Tør højttaleren af med en blød, damp klud. Brug ikke slibende rengøringsmidler, alkohol eller kemiske opløsningsmidler.
- Sørg for, at alle porte er tørre, før du oplader eller tilslutter kabler, især efter udsættelse for vand.
2. Vandtætning (IPX7)
Image: The UrbanX FM0190 speaker partially submerged in water, illustrating its IPX7 waterproof capability, allowing it to be used in wet environments.
- The IPX7 rating means the speaker can be submerged in water up to 1 meter for 30 minutes.
- Sørg altid for, at dækslet til opladningsporten er forsvarligt lukket, før højttaleren udsættes for vand.
- Avoid exposing the speaker to saltwater or chlorinated water for extended periods, as this may cause damage over time. Rinse with fresh water after exposure to such liquids.
3. Opbevaring
- Opbevar højttaleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
- Hvis batteriet opbevares i længere tid, skal det oplades til cirka 50% for at bevare batteriets tilstand.
Fejlfinding
If you encounter issues with your UrbanX FM0190 speaker, refer to the following common problems and solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Højttaleren tænder ikke. | Lavt batteri. | Oplad højttaleren i 3-4 timer. |
| Kan ikke parres via Bluetooth. | Højttaleren er ikke i parringstilstand; enhedens Bluetooth er slået fra; for langt fra højttaleren. | Ensure speaker is in pairing mode (flashing blue light). Turn Bluetooth off/on on your device. Move device closer to speaker (within 10 meters). |
| Ingen lyd under afspilning. | Lydstyrken er for lav; forkert inputtilstand; enhed ikke tilsluttet. | Increase speaker and device volume. Check if the correct input mode (Bluetooth, SD/TF, AUX) is selected. Re-pair Bluetooth device. |
| Dårlig lydkvalitet eller forvrængning. | Low battery; device too far; interference. | Charge the speaker. Move device closer. Avoid obstacles between speaker and device. |
| TWS-parring mislykkes. | Højttalere er allerede tilsluttet andre enheder; for langt fra hinanden. | Sørg for, at begge højttalere er frakoblet fra andre enheder. Placer højttalerne tæt på hinanden under TWS-parring. |
Hvis problemet fortsætter efter at have prøvet disse løsninger, bedes du kontakte kundesupport.
Specifikationer
Detailed technical specifications for the UrbanX FM0190 Waterproof Bluetooth Speaker:
| Feature | Specifikation |
|---|---|
| Mærke | UrbanX |
| Modelnummer | FM0190 |
| Forbindelsesteknologi | Bluetooth V5.2 |
| Højttaler Maksimal udgangseffekt | 5 watt |
| Vandtæt vurdering | IPX7 |
| Batterikapacitet | 1800 mAh Lithium-ion |
| Batteriets gennemsnitlige levetid | Up to 20 hours (actual battery life varies with usage) |
| Opladningstid | 3-4 timer |
| Kontrolmetode | Berøringsknapper |
| Materiale | ABS environmentally friendly plastic, nylon fabric, rubber oil, metal |
| Varedimensioner (D x B x H) | 13.7 cm D x 9.55 cm B x 9.7 cm H (5.4 cm D x 3.76 cm B x 3.82 cm H) |
| Varens vægt | 15 ounces (ca. 425 g) |
| Yderligere funktioner | Bass Boost, Shockproof, USB Port (for charging), Built-in Microphone, TWS Pairing |
Garanti og support
Garantioplysninger
The UrbanX FM0190 Waterproof Bluetooth Speaker comes with a 30 Days Money Back WarrantyGem venligst din købsbevis i tilfælde af garantikrav.
Kundesupport
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact UrbanX customer support through the retailer where you purchased the product or visit the official UrbanX webwebsted for kontaktoplysninger.
