1. Introduktion

This manual provides essential information for the safe installation, operation, and maintenance of your BG Electrical Double Switched Power Wall Plug Socket (Model: NFB22UAC45B-01). This product features two 13A switched sockets, one USB Type-A port, and one USB Type-C port, offering super-fast charging capabilities for compatible devices. Its sleek matt black finish and integrated USB charging eliminate the need for bulky adapters, providing a modern and efficient power solution.

Figure 1: BG Electrical Double Switched Power Wall Plug Socket (NFB22UAC45B-01)

The image displays the front of the matt black double wall socket. It features two standard 13A plug sockets, each with an individual switch. In the center, between the two main sockets, are a USB Type-C port (top) and a USB Type-A port (bottom). Markings indicate 45W (5-20V, max 3A) for the Type-C port and 30W (5-12V, max 3A) for the Type-A port. The overall design is sleek with rounded corners.

2. Sikkerhedsoplysninger

ADVARSEL: Electricity can be dangerous. This product must be installed by a competent person in accordance with the current IEE Wiring Regulations (BS 7671) and all applicable building regulations. If in doubt, consult a qualified electrician.

• Afbryd altid strømforsyningen, inden der påbegyndes elektrisk arbejde.
• Må ikke installeres i damp eller våde forhold.
• Sørg for, at alle forbindelser er sikre og korrekt tilsluttede.
• Do not overload the socket. Refer to the specifications for maximum load.
• Opbevares utilgængeligt for børn.
• Dette produkt er kun designet til indendørs brug.

3. Pakkens indhold

• 1 x BG Electrical Double Switched Power Wall Plug Socket (NFB22UAC45B-01)
• Fastgørelse af skruer

4. Produktfunktioner

• Slankt design: Matt black finish with softly rounded corners, black inserts, and colour-matching fixing screws for a modern aesthetic.
• Super Fast USB Charging: Features both USB Type-A (30W) and USB Type-C (45W) ports with variable voltage teknologi.
• Intelligent opladning: Justerer automatisk lydstyrkentage to provide optimal power to devices and activates standby mode to prevent overcharging once fully charged.
• Nem installation: Conveniently angled in-line colour-coded captive screw terminals simplify wiring.
• Fugtbeskyttelse: Fixed integrated plastic gasket protects metal edges from moisture, with no visible plastic around the switches.
• Universal kompatibilitet: Supports various charging protocols (e.g., PD & QC) for a wide range of USB devices, from smartphones to laptops.

5. Opsætning og installation

Installation should only be carried out by a qualified electrician or competent person. Ensure the mains power supply is isolated at the consumer unit/fuse box before proceeding.

1. Forbered ledningerne: Carefully strip the insulation from the live (brown), neutral (blue), and earth (green/yellow) wires to the appropriate length for the terminals.
2. Tilslut ledningerne:
   • Tilslut Live (L) wire to the terminal marked 'L'.
   • Tilslut Neutral (N) wire to the terminal marked 'N'.
   • Tilslut Jorden (E) wire to the terminal marked 'E'.


   Figure 2: Colour-Coded Terminals for Easy Wiring

   This image shows the rear of the socket with the transparent backplate removed, revealing the internal wiring terminals. The terminals are clearly marked L (Live, brown wire), N (Neutral, blue wire), and E (Earth, green and yellow wire). The design features retained screws, allowing wires to be easily slotted into place before tightening.

3. Secure the Socket: Once wired, carefully push the socket into the wall box (minimum 25mm deep back box recommended for retro-fit). Use the provided fixing screws to secure the socket to the wall box.
4. Gendan strøm: Når installationen er færdig, og alle tilslutninger er kontrolleret, skal strømforsyningen til forbrugerenheden/sikringsskabet genoprettes.

Figur 3: Slim Profile and Back Box Compatibility

The image illustrates the slim profile of the socket when installed, demonstrating how it fits flush against the wall. A transparent diagram of a 25mm back box is overlaid, indicating that the socket is designed to fit this standard size, making it suitable for both new installations and retrofitting.

6. Betjeningsvejledning

This socket provides both standard 13A power outlets and integrated USB charging ports.

• Using the 13A Sockets:

  Insert your appliance plug into one of the 13A sockets. Use the corresponding switch to turn the power on or off. The switches control the power to the 13A outlets only; the USB ports are independently powered.

• Using the USB Charging Ports:

  Connect your USB-A or USB-C compatible device charging cable to the respective port. The intelligent charging feature will detect your device and deliver the optimal power required, up to 45W for USB-C and 30W for USB-A. Charging will automatically stop or enter standby mode once the device is fully charged to prevent overcharging.



  Figure 4: Fast, Smart USB Charging in Use

  This image shows the matt black wall socket installed in a kitchen setting, with a laptop connected and charging via the USB-C port. The text highlights "Fast, Smart USB Charging with variable voltage technology" and "Only delivering the power a device needs, never over-charging," illustrating the intelligent charging capabilities.



  Figure 5: Universal USB Compatibility

  The image displays a range of electronic devices, including smartphones (Google Pixel, Samsung, iPhone), an Apple Watch, and a laptop, all positioned around the text "Universal Compatibility supports PD & QC charging protocols." This visually confirms the socket's ability to charge a wide array of USB-powered devices using its 45W USB A+C ports.

7. Vedligeholdelse

To maintain the appearance and functionality of your socket:

• Sørg for, at strømmen er slukket før rengøring.
• Wipe the surface with a soft, dry cloth. Do not use abrasive cleaners, solvents, or polishes as these may damage the finish.
• Do not allow liquids to enter the socket or USB ports.

8. Fejlfinding

• No Power to 13A Sockets:
  • Check if the individual switch on the socket is in the 'ON' position.
  • Verify that the mains power supply to the circuit is active at the consumer unit/fuse box.
  • Ensure the appliance plug is fully inserted.
• USB-porte oplader ikke:
  • Ensure the USB cable is fully and securely inserted into both the device and the socket's USB port. Some USB-C cables may require a firm connection.
  • Try a different USB cable to rule out cable fault.
  • Test with a different device to confirm the issue is not with the device itself.
  • Confirm the device is compatible with USB charging and its power requirements are within the socket's output capabilities (45W USB-C, 30W USB-A).
• Socket Feels Loose in Wall:
  • ADVARSEL: Isolate power before attempting to tighten screws.
  • Carefully tighten the fixing screws. If the issue persists, the wall box may be damaged or incorrectly installed, requiring professional attention.

9. Specifikationer

10. Garanti og support

BG Electrical products are manufactured to the highest standards and are guaranteed against faulty materials and workmanship for a period of 10 år from the date of purchase. This warranty covers defects arising from faulty materials or workmanship only. It does not cover damage caused by improper installation, misuse, accidental damage, or normal wear and tear.

For returns, the product typically has a 30 dages returret from the point of purchase, subject to the retailer's terms and conditions.

For technical support, warranty claims, or further assistance, please contact British General customer service. Refer to the official British General webwebsted for kontaktoplysninger.
