QINIZX Mini 6-tasters makro mekanisk tastatur brugermanual

Indledning

This manual provides comprehensive instructions for the setup, operation, and configuration of your QINIZX Mini 6-Key Macro Mechanical Keypad. This compact, programmable keypad is designed for various applications, including gaming, office tasks, and specialized functions, offering customizable key assignments and RGB backlighting.

Pakkens indhold

Kontroller venligst, at alle varer er til stede i pakken:

• 1 x QINIZX Mini 6-Key Macro Mechanical Keypad
• 1 x USB-C to USB Cable (1.5m)

Image: The QINIZX Mini 6-Key Macro Mechanical Keypad shown with its included USB-C to USB cable.

Specifikationer

Image: The compact size of the keypad shown in hand, and a view of its base with non-slip pads and dimensions.

Opsætningsinstruktioner

1. Hardwareforbindelse

1. Connect the provided USB-C to USB cable to the Type-C port on the keypad.
2. Sæt den anden ende af USB-kablet i en ledig USB-port på din computer.
3. The keypad is plug-and-play for basic HID functionality. For custom programming, proceed to the software installation steps.

Billede: Side view of the keypad highlighting the USB-C connection port.

2. Software Installation and Configuration (Windows Required for Setup)

To fully customize the keypad's functions and RGB lighting, you need to use the dedicated configuration software. Note: The software is Windows-based. If you intend to use the keypad with Mac OS or Linux, you must perform the initial configuration on a Windows computer. The keypad has a memory function and will retain its settings when moved to another operating system.

1. Download softwaren: Visit the official software webwebsted: https://key.itytsoft.com/. You may also find a direct link to the English software manual (6key_en.docx) on the same site.
2. Forbered til installation: Some antivirus software may flag the executable file (.exe) as a potential threat. This is a common occurrence for custom utility software. Temporarily disable your PC's protection software if you encounter issues during download or execution.
3. Extract and Run: Download Setting.zip file, extract its contents, and locate the Run-me.exe file. Dobbeltklik Run-me.exe to launch the configuration software.
4. Vælg sprog: If the software is not in English, look for an "English" or "ENGLISH" button to switch the interface language.
5. Connect and Detect: Ensure your keypad is connected to the computer. In the software, click "SearchDevice" to detect your keypad. Once detected, click "Configure". If the software shows "unconnected" after 10 seconds, try a different USB port or restart your computer.

Image: Visual guide for downloading and launching the keypad configuration software.

Operating Modes and Key Configuration

The configuration software allows you to assign various functions to each of the 6 keys. Each key can operate independently in one of four modes:

• Tastaturtilstand: Assign standard keyboard keys (e.g., A, B, C, Ctrl, Shift, Alt). Multiple key combinations are supported.
• Musetilstand: Assign mouse functions (e.g., left click, right click, middle click, scroll up/down, mouse movement).
• Multimedietilstand: Assign multimedia controls (e.g., Play/Pause, Stop, Volume Up/Down, Mute, Next/Previous Track).
• Multi-key Mode (Macro): Create macros by assigning a sequence of up to 15 key presses. You can also add an interval time between key presses for specific applications (e.g., one-key password entry).

Configuring Keys:

1. In the software interface, select the key you wish to configure.
2. Choose the desired mode (Keyboard, Mouse, Multimedia, Multi-key) from the dropdown menu for that key.
3. Follow the on-screen prompts to select the specific function or sequence of keys. For multi-key mode, click the keys you need to input one by one.
4. After configuring all desired keys, click the "Save to Keyboard" button to apply the settings. A "save successfully" message will confirm the update.

Image: Software interface demonstrating key mode selection and assignment for various functions.

RGB Backlight Settings

The keypad features customizable RGB LED backlighting. You can adjust the lighting effects and colors through the configuration software.

1. Within the configuration software, locate the "LED setting" section.
2. Select from various LED modes, including static colors (red, green, blue, yellow, cyan, white, purple), flow modes, and a default colorful gradient mode that constantly brightens and slowly changes color.
3. After selecting your preferred lighting effect, click "Save to Keyboard" to apply the changes.

Image: The keypad displaying different RGB backlight colors and effects.

Opretholdelse

Generel pleje:

• Keep the keypad clean by wiping it with a soft, dry cloth.
• Avoid exposing the keypad to excessive moisture or extreme temperatures.
• Brug ikke hårde kemikalier eller slibende rengøringsmidler.

Hot-swap-kontakter:

The QINIZX Mini 6-Key Macro Mechanical Keypad features hot-swappable switches, allowing you to replace the default Red switches with other compatible 3-pin or 5-pin mechanical switches without soldering. You can also replace the keycaps with standard Cherry MX compatible keycaps.

1. Fjernelse af nøglekapsel: Use a keycap puller to gently remove the keycaps.
2. Fjernelse af switch: Use a switch puller to carefully remove the mechanical switch from its socket. Apply even pressure to avoid damaging the PCB or switch pins.
3. Kontaktinstallation: Align the pins of the new switch with the holes on the PCB. Press down gently until the switch clicks into place. Ensure the pins are straight before insertion to prevent bending.
4. Installation af tastatur: Place the new keycap onto the switch stem and press down firmly.

Billede: View of the keypad's hot-swappable switch socket, along with a detached keycap and mechanical switch.

Fejlfinding

• Tastaturet reagerer ikke:
  • Sørg for, at USB-kablet er korrekt tilsluttet til både tastaturet og computeren.
  • Prøv at tilslutte tastaturet til en anden USB-port på din computer.
  • Genstart din computer, og prøv igen.
  • Test the keypad on another computer if possible to rule out a computer-specific issue.
• Configuration Software Not Detecting Keypad:
  • Verify the keypad is connected and powered on.
  • Ensure you have downloaded the correct software from https://key.itytsoft.com/.
  • Deaktiver midlertidigt enhver antivirus- eller firewallsoftware, der muligvis blokerer applikationen.
  • Try running the software as an administrator.
  • If the software shows "unconnected" after 10 seconds, try a different USB port or restart your computer.
• Keys Not Performing Assigned Functions:
  • Reconnect the keypad and reopen the configuration software.
  • Verify that the desired functions are correctly assigned to each key in the software.
  • Ensure you clicked "Save to Keyboard" after making changes.
  • If using on Mac/Linux, confirm that the configuration was saved on a Windows machine first.
• RGB Backlight Not Working or Incorrect:
  • Check the LED settings in the configuration software.
  • Ensure the desired lighting mode is selected and saved to the keypad.

Garanti og support

For warranty information or technical support, please refer to the retailer where you purchased the QINIZX Mini 6-Key Macro Mechanical Keypad or visit the official QINIZX webwebstedet for kontaktoplysninger. Gem venligst din købsbevis til garantikrav.
