LAXIHUB M1 1080P Full HD Security Baby Monitor User Manual

Indledning

This manual provides detailed instructions for the installation, operation, and maintenance of your LAXIHUB M1 1080P Full HD Security Baby Monitor. Please read this manual thoroughly before using the product to ensure proper functionality and safety. Keep this manual for future reference.

Image: LAXIHUB M1 Baby Pet Camera overview.

Hvad er der i æsken

Bekræft at alle komponenter er til stede i pakken:

• LAXIHUB M1 Security Baby Monitor (Quantity: 2 for 2-pack, 1 for single pack)
• Strømadapter
• USB kabel
• Monteringstilbehør (skruer, vægankre)
• Brugermanual

Image: Diagram showing the camera and its accessories for easy setup.

Produktegenskaber

• 1080P Full HD-video: Provides clear and detailed live and recorded footage.
• Bevægelses- og lyddetektion: Alerts you to activity and sounds in the monitored area.
• Nattesyn: Equipped with IR LEDs for clear viewing in low-light conditions up to 10 meters.
• Tovejs lyd: Allows for real-time communication through the camera's built-in speaker and microphone.
• 2.4G WiFi-forbindelse: Connects to your home network for remote access.
• Smart Assistant-kompatibilitet: Works with Amazon Alexa and Google Assistant for voice control and viewing.
• Fleksible opbevaringsmuligheder: Supports local MicroSD card storage and cloud storage (subscription may be required).
• Geofence Mode: Offers privacy protection by automatically turning off recording when you are home.

Image: Comparison of day and night vision clarity for the LAXIHUB M1 monitor.

Image: Illustration of the two-way audio function for communication.

Opsætningsvejledning

1. Download appen: Søg efter the "Arenti" app on your smartphone's app store (iOS or Android) and install it.
2. Opret en konto: Open the Arenti app and follow the on-screen instructions to create a new user account.
3. Tænd for enheden: Connect the camera to a power source using the provided USB cable and power adapter. The camera will power on and its indicator light will begin to flash.
4. Tilføj enhed: In the Arenti app, tap the "+" icon to add a new device. Select the LAXIHUB M1 camera from the list.
5. Opret forbindelse til Wi-Fi: Follow the app's instructions to connect the camera to your 2.4GHz Wi-Fi network. Ensure your phone is connected to the same 2.4GHz network during setup.
6. Scan QR -kode: The app will display a QR code. Hold your phone with the QR code in front of the camera lens (approximately 15-25 cm or 5-8 inches away) until you hear a confirmation sound from the camera.
7. Komplet opsætning: Once the camera connects, follow the remaining prompts in the app to name your camera and finalize the setup.

Image: Visual guide for the easy setup process using the app and QR code.

Betjeningsvejledning

Levende View

Open the Arenti app and select your camera to view the live feed. You can pinch to zoom, take screenshots, or record video directly from the live view.

Bevægelses- og lyddetektering

The camera is equipped with advanced motion and sound detection. When activity or noise is detected, you will receive instant alerts on your smartphone. Sensitivity levels can be adjusted in the app settings.

Image: The LAXIHUB M1 camera detecting motion from a baby.

To-vejs lyd

To use two-way audio, tap the microphone icon in the live view within the app. You can then speak through your phone, and your voice will be transmitted through the camera's speaker. Release the icon to listen.

Nattesyn

The camera automatically switches to night vision mode in low-light conditions, providing clear black and white images. The infrared range is up to 10 meters.

Opbevaringsmuligheder

• MicroSD-kort: Insert a MicroSD card (up to 128GB, not included) into the designated slot for local continuous recording.
• Cloud Storage: Subscribe to the cloud service for secure online storage of your recordings. This allows access to historical videos even if the camera is offline.

Image: Close-up of the MicroSD card slot on the LAXIHUB M1 camera.

Smart Assistant-integration

The LAXIHUB M1 is compatible with Amazon Alexa and Google Assistant. Follow the instructions in your smart assistant app to link your Arenti account and enable voice commands for viewdit kamerafeed på kompatible enheder.

Image: The LAXIHUB M1 camera integrated with an Alexa-enabled smart display.

Deling af flere brugere

You can share access to your camera with family members or trusted individuals through the Arenti app. This allows multiple users to view the live feed and receive alerts simultaneously.

Image: Illustration of the multi-user sharing feature for the LAXIHUB M1 camera.

Opretholdelse

• Rensning: Brug en blød, tør klud til at rengøre kameralinsen og huset. Undgå slibende rengøringsmidler eller opløsningsmidler.
• Firmwareopdateringer: Regularly check the Arenti app for available firmware updates to ensure optimal performance and security.
• Placering: Sørg for, at kameraet er placeret et stabilt sted, væk fra direkte sollys, varmekilder og fugt.

Fejlfinding (spørgsmål og svar)

Q: Will this work if not connected to Wi-Fi?

A: No. The wireless camera requires a network connection to function.

Q: How many people can view the camera app at the same time?

A: There is no limit. You can share access with multiple people.

Q: Will it send an alert if the power goes off?

A: No, the indoor camera requires continuous power to operate and send alerts.

Q: Can this device be used without the cloud service?

A: Yes, you can use the camera without a cloud subscription. However, historical videos will not be accessible. You can use an SD card for local storage of recordings.

Q: What is the maximum distance to the Wi-Fi router?

A: The effective range depends on the Wi-Fi router signal strength. Normally, the security camera supports 10-20 meters without obstructions.

Q: Can I use two cameras and view them on the same app screen?

A: Yes. Using one app, you can view different cameras and switch between them by swiping.

Specifikationer

Garanti og support

For warranty information and technical support, please refer to the official LAXIHUB webwebstedet eller kontakt deres kundeservice direkte. Gem din købskvittering som købsbevis i tilfælde af garantikrav.

Fabrikant: LAXIHUB

Webwebsted: LAXIHUB Official Store
