Indledning
This manual provides essential information for the safe and efficient use of your Aigostar LED PLC G24d-3 15W bulbs. Please read these instructions carefully before installation and retain them for future reference.
Sikkerhedsinstruktioner
- Sluk: Always ensure the power supply is switched off at the mains before installing, removing, or cleaning the bulb.
- Korrekt base: Use only in fixtures designed for G24d-3 bi-pin bases. Incorrect base types can cause damage or electrical hazards.
- Ikke-dæmpbar: Denne pære kan ikke dæmpes. Må ikke anvendes med lysdæmpere, da dette kan beskadige pæren og ugyldiggøre garantien.
- Kun indendørs brug: Designed for indoor applications. Do not expose to moisture or outdoor elements.
- Ventilation: Ensure adequate ventilation around the bulb to prevent overheating.
- Bortskaffelse: Dispose of LED bulbs according to local regulations. Do not dispose of with general household waste.
- Børn: Opbevares utilgængeligt for børn.
Produkt overview
The Aigostar LED PLC G24d-3 15W bulb is an energy-efficient lighting solution designed for various indoor applications. It features a long lifespan and provides neutral white light (4000K) with high color rendering.
Image: Key parameters of the Aigostar LED PLC G24d-3 15W bulb, including 15W wattage, 101W incandescent equivalent, 1540 lumens brightness, non-dimmable feature, neutral white 4000K color temperature, and G24d-3 base type. Dimensions are shown as 3.4cm width and 17cm height.
- Lang levetid: Semiconductor light-emitting chip design ensures a long operational life of up to 15,000 hours, reducing the frequency of replacements.
- Energieffektiv: Consumes significantly less electricity compared to traditional bulbs, contributing to energy savings.
- Nem installation: Standard G24d-3 base allows for instant, flicker-free, and hum-free illumination.
- Bred anvendelse: High-quality glass with a 360° beam angle, suitable for downlights, table lamps, and various commercial, industrial, and home lighting environments.
- Høj ydeevne: Features a Color Rendering Index (CRI) of >80 for accurate color perception, short-circuit protection, high-temperature protection, and durable heat-resistant PC material.
Billede: Eksamples of the Aigostar LED PLC G24d-3 15W bulb's application in various settings, including industrial, commercial, and home lighting, demonstrating its 360-degree light distribution.
Opsætning (Installation)
- Sluk for strømmen: Before starting, ensure the electrical power to the fixture is completely turned off at the circuit breaker or fuse box.
- Fjern gammel pære: Carefully remove the existing bulb from the fixture. Allow it to cool if it was recently in use.
- Indsæt ny pære: Align the G24d-3 bi-pin base of the Aigostar LED bulb with the socket in the fixture. Gently push and twist until the bulb is securely seated. Do not force the bulb into the socket.
- Gendan strøm: Når pæren er sikkert installeret, skal du genoprette strømmen til armaturet ved afbryderen.
- Prøve: Tænd lyskontakten for at bekræfte korrekt funktion.
Drift
The Aigostar LED PLC G24d-3 15W bulb operates as a standard light source. Simply use the wall switch or fixture switch to turn the light on or off. This bulb is non-dimmable and should not be used with dimmer switches.
Image: Comparison illustrating the flicker-free operation of Aigostar LED bulbs versus the frequent flicker of ordinary bulbs, highlighting eye protection benefits.
Image: Illustration of the Color Rendering Index (CRI) of the Aigostar LED bulb, showing CRI > 80, which provides colors close to natural sunlight for enhanced visual accuracy.
Opretholdelse
- Rensning: Sørg for, at strømmen er slukket, og at pæren er kold, inden rengøring. Tør pæren af med en blød, tør klud. Brug ikke flydende rengøringsmidler eller slibende materialer.
- Udskiftning: Due to the long lifespan of LED bulbs, frequent replacement is not expected. When replacement is necessary, follow the installation steps outlined in the "Setup" section.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Pæren lyser ikke. |
|
|
| Pæren flimrer eller brummer. |
|
|
Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Aigostar |
| Modelnavn | Aigostar PLC 2U 15W G24 Neutralweiß |
| ASIN | B097RC3X8M |
| Pære type | LED |
| Pære form | PLC 2U |
| Base Type | G24d-3 bi-pin |
| Wattage | 15 watt |
| Glødelignende ækvivalent | 101 watt |
| Lysstrøm | 1540 lumen |
| Farvetemperatur | 4000 Kelvin (Neutral hvid) |
| Color Rendering Index (CRI) | >80 |
| Voltage | 220-240 Volt, 50 Hertz |
| Dæmpbar | Nej (ikke-dæmpbar) |
| Levetid | Op til 15,000 timer |
| Materiale | Plast, glas |
| Dimensioner (L x B x H) | 3.4 x 3.4 x 17 cm (approx. per bulb) |
| Energieffektivitetsklasse | F (New EU standard, equivalent to old A+) |
| Indendørs/Udendørs brug | Indendørs |
| Oprindelsesland | Kina |
Image: The EU Energy Label for the Aigostar PLC 2U 15W G24d-3 LED bulb, showing an energy efficiency class of F under the new 2019/2015 regulations. Click the image to view the product on the EPREL database.
Garanti og support
Aigostar products are manufactured to high-quality standards. For information regarding warranty coverage, technical support, or customer service, please refer to the contact details provided on the product packaging or visit the official Aigostar webwebsted. Gem venligst din købsbevis til garantikrav.
