ledmo 120W LED Wall Pack Light Instruction Manual

Indledning

This manual provides detailed instructions for the safe installation, operation, and maintenance of your ledmo 120W LED Wall Pack Light. Please read this manual thoroughly before installation and retain it for future reference.

Image: The ledmo 120W LED Wall Pack Light, showcasing its design and typical outdoor installation.

Sikkerhedsoplysninger

Always follow basic safety precautions when installing or servicing electrical equipment to reduce the risk of fire, electric shock, or injury to persons.

• Afbryd strømmen: Ensure power is turned off at the circuit breaker or fuse box before installation or maintenance.
• Uddannet elektriker: Installationen skal udføres af en kvalificeret elektriker i overensstemmelse med alle nationale og lokale el-forskrifter.
• Jording: Properly ground the fixture to avoid potential electrical shock.
• Voltage Kompatibilitet: Kontroller, at forsyningen voltage er kompatibel med armaturets krav (110 volt).
• Sikker montering: Mount the fixture securely to a structurally sound surface.
• Undgå direkte øjeneksponering: Se ikke direkte ind i LED-lyskilden, når den er tændt.

Pakkens indhold

Kontroller, at alle komponenter er til stede, før installationen påbegyndes:

• 1 x ledmo 120W LED Wall Pack Light Fixture
• 1 x Light kit (mounting hardware)

Specifikationer

Installationsvejledning

The ledmo 120W LED Wall Pack Light is designed for straightforward installation. Two primary methods are supported: direct wall mount or junction box installation.

1. Forberedelse

• Strømafbrydelse: Sluk for hovedstrømforsyningen ved afbryderen, før du påbegynder elektrisk arbejde.
• Nødvendige værktøjer: Gather necessary tools including a screwdriver, wire strippers, drill, and appropriate mounting hardware.
• Valg af sted: Choose a suitable outdoor location for mounting, ensuring the surface can support the fixture's weight and provides adequate light coverage.

Image: The updated design of the 120W LED Wall Pack Light is smaller and lighter, simplifying installation and reducing stress on mounting surfaces.

2. Montering af armaturet

The fixture can be mounted directly to a wall or to a standard junction box.

• Vægbeslag: Use the provided mounting hardware to secure the fixture directly to the wall. Ensure the mounting screws are driven into solid structural elements.
• Forgreningsboksmontering: Align the fixture with the existing junction box. Use the appropriate screws to attach the fixture securely to the junction box.

Image: Illustration of the two flexible installation methods: directly to a wall or via a junction box.

3. Ledninger

Connect the electrical wires according to standard electrical codes:

• Tilslut sort ledningen fra armaturet til live (hot) ledningen fra strømforsyningen.
• Tilslut hvid ledningen fra armaturet til neutral ledningen fra strømforsyningen.
• Tilslut grøn (or bare copper) wire from the fixture to the jord ledningen fra strømforsyningen.
• Ensure all connections are secure using wire nuts or appropriate connectors.

After wiring, carefully tuck all wires into the junction box or fixture housing and secure the fixture cover.

Video: A demonstration of the ledmo 120W LED Wall Pack Light's brightness and coverage in an outdoor setting, highlighting its suitability for yards and commercial spaces.

Betjeningsvejledning

Once installed and wired correctly, the ledmo 120W LED Wall Pack Light operates via a standard electrical switch. Some models may include a photocell for automatic dusk-to-dawn operation (if specified in your product variant).

• Manuel kontrol: Use the connected wall switch to turn the light ON or OFF.
• Photocell Operation (if applicable): If your model includes a photocell, the light will automatically turn on when ambient light levels drop (dusk) and turn off when light levels rise (dawn). Ensure the photocell is not obstructed.

Image: The ledmo 120W LED Wall Pack Light provides extensive and bright illumination for large outdoor areas.

Image: The wide-beam optics ensure broad light distribution, covering significant distances from the mounting point.

Opretholdelse

The ledmo 120W LED Wall Pack Light is designed for minimal maintenance due to its durable construction and long-lasting LED components.

• Rensning: Rengør linsen og huset regelmæssigt med en blød kludamp cloth to remove dirt, dust, or debris that may accumulate and affect light output. Do not use abrasive cleaners.
• Inspektion: Annually inspect the fixture for any signs of damage, loose wiring, or corrosion. Ensure all mounting screws remain tight.
• Vandtæt forsegling: The fixture features an IP65 waterproof rating. Avoid disassembling the sealed components, as this may compromise the waterproof integrity.

Image: The IP65 waterproof design ensures the fixture's durability and performance in various outdoor weather conditions.

Fejlfinding

If you encounter issues with your ledmo LED Wall Pack Light, refer to the following common troubleshooting steps:

• Lyset tænder ikke:
  • Kontroller afbryderen for at sikre, at der er strøm til armaturet.
  • Kontroller, at alle ledningsforbindelser er sikre og korrekte.
  • If equipped with a photocell, ensure it is not covered or obstructed, which might prevent it from activating at dusk.
• Lysflimmer:
  • Tjek for løse ledningsforbindelser.
  • Sørg for, at voltagForsyningen er stabil og inden for det angivne område.
• Reduceret lysstyrke:
  • Clean the lens and housing to remove any accumulated dirt or debris.
  • Ensure the fixture is receiving adequate power.

Hvis disse trin ikke løser problemet, bedes du kontakte kundesupport.

Garantioplysninger

The ledmo 120W LED Wall Pack Light comes with a Begrænset garanti. Please refer to the product packaging or contact ledmo customer support for specific terms and conditions regarding your warranty coverage.

Kundesupport

For further assistance, technical support, or warranty claims, please contact ledmo customer service through the retailer where the product was purchased or visit the official ledmo webwebsted.

Fabrikant: targetlighting
