Dyson DC21 Stowaway Canister Vacuum User Manual

1. Introduktion

The Dyson DC21 Stowaway Canister Vacuum is engineered for effective home cleaning, featuring constant suction technology and a compact design for convenient storage. This manual provides essential information for the safe and efficient operation and maintenance of your vacuum cleaner.

2. Vigtige sikkerhedsinstruktioner

To reduce the risk of fire, electric shock, or injury, read all instructions before using this vacuum cleaner.

• Læs alle instruktioner før brug.
• Må ikke bruges udendørs eller på våde overflader.
• Tag stikket ud af stikkontakten, når den ikke er i brug, og før servicering.
• Må ikke bruges som legetøj. Omhyggelig opmærksomhed er nødvendig, når den bruges af eller i nærheden af ​​børn.
• Brug kun som beskrevet i denne manual. Brug kun producentens anbefalede tilbehør.
• Må ikke bruges med en beskadiget ledning eller stik. Hvis apparatet ikke fungerer, som det skal, er blevet tabt, beskadiget, efterladt udendørs eller tabt i vand, skal det returneres til et servicecenter.
• Undlad at trække eller bære i snoren, bruge snoren som håndtag, lukke en dør på snoren eller trække snoren rundt om skarpe kanter eller hjørner. Kør ikke apparatet over ledningen. Hold ledningen væk fra opvarmede overflader.
• Tag ikke stikket ud ved at trække i ledningen. For at tage stikket ud skal du tage fat i stikket, ikke i ledningen.
• Håndter ikke stikket eller apparatet med våde hænder.
• Stik ikke genstande ind i åbninger. Må ikke bruges med blokerede åbninger; holdes fri for støv, fnug, hår og alt, hvad der kan reducere luftstrømmen.
• Hold hår, løstsiddende tøj, fingre og alle dele af kroppen væk fra åbninger og bevægelige dele.
• Tag ikke noget op, der brænder eller ryger, såsom cigaretter, tændstikker eller varm aske.
• Vær ekstra forsigtig ved rengøring på trapper.
• Må ikke bruges til at opsamle brændbare eller brændbare væsker, såsom benzin, eller brug i områder, hvor de kan være til stede.
• Må ikke bruges uden støvbeholder og/eller filtre på plads.

3. Opsætning og montering

1. Udpak komponenter: Fjern forsigtigt alle dele fra emballagen.
2. Fastgør slange: Connect the flexible hose to the main vacuum unit. Ensure it clicks securely into place.
3. Connect Wand: Attach the telescopic wand to the hose handle.
4. Fastgør rengøringshoved: Secure the desired cleaning head (e.g., motorized brush bar or hard-floor tool) to the end of the wand. Ensure all connections are firm before operating.

Figure 3.1: The Dyson DC21 Stowaway Canister Vacuum fully assembled with hose, wand, and cleaning head.

4. Betjeningsvejledning

1. Strømtilslutning: Plug the power cord into a suitable electrical outlet. The cord length is approximately 16-2/5 feet.
2. Tænd/sluk: To turn on the vacuum, press the power button located on the main unit or handle. Press again to turn off.
3. Brush Bar Control: For carpeted surfaces, activate the brush bar using its on/off switch. For hard floors, ensure the brush bar is off to prevent scratching and potential damage.
4. Rensning: Guide the cleaning head over the surface to be cleaned. The vacuum is designed to maintain constant suction power.
5. Udvidet rækkevidde: The extendable wand allows for convenient cleaning of stairs and high-reach areas.
6. Efterbehandling: When cleaning is complete, turn off the vacuum and unplug it from the outlet.

Figure 4.1: The vacuum head in operation, demonstrating effective dirt pickup from carpeted surfaces.

5. Vedligeholdelse

5.1. Tømning af støvbeholderen

The vacuum features a 4/9-gallon dust bin. Empty the bin when debris reaches the MAX fill line.

1. Remove Bin: Press the bin release button to detach the dust bin from the main unit.
2. Tøm affald: Hold the bin over a trash receptacle. Press the red button to open the bottom flap and release the collected debris.
3. Reattach Bin: Close the bottom flap securely until it clicks into place. Reattach the bin to the main vacuum unit.

5.2. Rengøring af HEPA-filteret

The DC21 includes a lifetime HEPA filter designed to capture microscopic particles. Regular cleaning ensures optimal performance.

1. Find filter: Identify the filter compartment, typically positioned near the dust bin.
2. Fjern filter: Fjern forsigtigt HEPA-filteret.
3. Vask filter: Wash the filter with cold water only. Do not use detergents or place in a dishwasher.
4. Tørt filter: Allow the filter to air dry completely for a minimum of 24 hours before reinserting. Ensure it is absolutely dry to prevent damage to the motor.
5. Geninstaller filter: Once dry, reinsert the filter into its compartment and secure it.

Figur 5.1: Intern view of the Dyson DC21, highlighting the cyclone technology and filter location for maintenance.

5.3. Fjernelse af blokeringer

If suction power decreases significantly, check the hose, wand, and cleaning head for any obstructions. Carefully remove any blockages to restore full suction.

Figure 5.2: The Dyson DC21 in its compact storage configuration, demonstrating how the hose and wand can be neatly stowed.

6. Fejlfinding

Problem: Ingen strøm

• Check if the power cord is securely plugged into a functional electrical outlet.
• Verify the outlet is operational by testing with another appliance.
• Check for tripped circuit breakers in your home's electrical panel.

Problem: Loss of Suction

• Empty the dust bin if it is full or debris has reached the MAX fill line.
• Inspect the hose, wand, and cleaning head for any blockages and remove them.
• Ensure the HEPA filter is clean and completely dry before reinstallation.
• Verify all connections (hose to unit, wand to hose, cleaning head to wand) are secure.

Problem: Brush Bar Not Rotating

• Ensure the brush bar on/off switch is in the 'on' position.
• Check for obstructions such as hair, threads, or debris wrapped around the brush bar. Carefully remove any entanglements.
• If the brush bar bogs down on thick carpet, it may be due to excessive resistance; ensure the brush bar is clean and free of debris.

7. Specifikationer

8. Garanti og support

This Dyson DC21 Stowaway Canister Vacuum comes with a 5 års garanti covering parts and labor for defects in materials and workmanship from the date of purchase.

For warranty claims, technical assistance, or to order replacement parts, please contact Dyson customer support. Refer to your purchase documentation for specific contact details or visit the official Dyson webwebstedet for de mest opdaterede supportoplysninger.

Gem venligst din købsbevis af garantihensyn.
